Knee

Procedure

Quadrizepssehnentransplantate bieten bei der Kreuzbandrekonstruktion einzigartige Vorteile, wie beispielsweise einen kalkulierbaren großen Durchmesser, eine verringerte Morbidität1 und eine geeignete Steifigkeit für die Bandrekonstruktion im Knie.
Der QuadPro-Sehnenstripper ist für eine sichere, einfache und schnelle Entnahme eines Quadrizeps- oder Patellarsehnentransplantats unter Anwendung einen minimal-invasiven Technik konzipiert.2-4 Die scharfe Spitze schneidet ein etwa zylindrisches Transplantat aus. Sein Handgriff mit ergonomischem Design verfügt auf dem durchsichtigen Schaft über Skalen, auf denen die ungefähre Transplantatlänge während der Entnahme visualisiert wird. In vier Größen (8 bis 11 mm) erhältlich, sodass der QuadPro-Sehnenstripper die einzigartigen Anforderungen jedes Patienten sowie die Präferenzen des Operateurs hinsichtlich des Transplantatdurchmessers berücksichtigt.
Das FiberTag-TightRope-Implantat erleichtert die Fixierung von Transplantaten mit nur einem Ende, z. B. Quadrizepssehnentransplantate, an den ACL TightRope-RT- und ABS-Implantaten. Der FiberTag-Faden ist in das TightRope-Implantat integriert und sorgt für eine feste, gleichmäßige Verbindung zwischen dem Faden und der TightRope-Schlaufe. Die vereinfachte Nahttechnik, die innovative Verpackung und das neue Hakenzangeninstrument zur Transplantatpräparation beschleunigen die Präparation von Quadrizepssehnentransplantaten und sorgen für mehr Reproduzierbarkeit als je zuvor.
Referenzen
1. Arthrex, Inc. LA1-00100-EN_K. Naples, FL; 2021.
2. Xerogeanes JW, Mitchell PM, Karasev PA, Kolesov IA, Romine SE. Anatomic and morphological evaluation of the quadriceps tendon using 3-dimensional magnetic resonance imaging reconstruction: applications for anterior cruciate ligament autograft choice and procurement. Am J Sports Med.2013;41(10):2392-2399. doi:10.1177/0363546513496626
3. Hadjicostas PT, Soucacos PN, Berger I, Koleganova N, Paessler HH. Comparative analysis of the morphologic structure of quadriceps and patellar tendon: a descriptive laboratory study. Arthroscopy. 2007;23(7):744-750. doi:10.1016/j.arthro.2007.01.032
4. Krebs N, Yaish A, O’Neill N. Anatomic evaluation of the quadriceps tendon in cadaveric specimens: application for anterior cruciate ligament reconstruction graft choice. SMRJ. 2019;4(1):7961. doi:10.51894/001c.7961

The QuadPro™ tendon harvester is the latest innovation for harvesting the quadriceps tendon using a minimally invasive technique. It was designed based on published anatomic studies and allows surgeons to safely and reproducibly harvest a graft of a desired length and diameter through a small incision and in a time-efficient manner.1-3 The system has the versatility to create grafts to meet the surgeon’s needs, whether the grafts be all soft tissue or with a bone block. The single-use design ensures sharpness, sterility, and convenience for every case.
References
1. Xerogeanes JW, Mitchell PM, Karasev PA, Kolesov IA, Romine SE. Anatomic and morphological evaluation of the quadriceps tendon using 3-dimensional magnetic resonance imaging reconstruction: applications for anterior cruciate ligament autograft choice and procurement. Am J Sports Med. 2013;41(10):2392-2399. doi:10.1177/0363546513496626
2. Hadjicostas PT, Soucacos PN, Berger I, Koleganova N, Paessler HH. Comparative analysis of the morphologic structure of quadriceps and patellar tendon: a descriptive laboratory study. Arthroscopy. 2007;23(7):744-750. doi:10.1016/j.arthro.2007.01.032
3. Krebs N, Yaish A, O’Neill N. Anatomic evaluation of the quadriceps tendon in cadaveric specimens: application for anterior cruciate ligament reconstruction graft choice. Spartan Med Res J. 2019;4(1)7961. doi:10.51894/001c.7961

Not Hidden

English  - en

video

Human

A general overview including the relevant steps of an Arthrex surgical technique. These animations always include a voice-over explaining the process.

Eine allgemeine Übersicht, einschließlich der relevanten Schritte einer Arthrex Operationsanleitung. Diese Animationen enthalten immer Voice-Overs, die den Prozess erklären.

Operationstechnik-Animationen

Visão geral incluindo as etapas relevantes de uma técnica cirúrgica Arthrex. Essas animações sempre incluem uma narração explicando o processo.

Animações de técnicas cirúrgicas

Descripción general que incluye los pasos relevantes de una técnica quirúrgica de Arthrex. Estas animaciones siempre incluyen una voz en off que explica el proceso.

Animaciones de técnicas quirúrgicas

Surgical Technique Animations

QuadPro™ Tendon Harvester Graft Harvesting System

The quadriceps tendon was first described as an acceptable graft option for ACL reconstruction in 1979. Arthrex introduced a minimally invasive instrumentation set in 2014, enabling a safe, easy and more reproducible quadriceps tendon harvest between 2015 and 2019. Arthrex released the FiberLoop with FiberTag and FiberTag TightRope implants to further improve performance and efficiency. The QuadPro tendon harvester is the next evolution in this ACL reconstruction portfolio. The QuadPro clear handle enables direct visualization of the graft to ensure the appropriate length is harvested. Quadpro is also available in sizes eight millimeters through 11mm. Its sharp tip harvests a smooth cylindrical graft. This minimally invasive harvesting technique reduces graft site morbidity and overall procedure time. Once an appropriate length of tendon is stripped, the graft can be retrieved through the amputation window when the push rod is deployed. The sharp edge in the window will cut the graft. Make a small transverse incision, approximately one centimeter proximal to the patella. Dissect the subcutaneous fat and remove it proximally and distally in the incision. A key elevator can be used to clear soft tissue proximally and distally. A retractor can be used while an arthroscope is guided proximally to visualize the tendon. Identify the VMO and stay lateral to this landmark. Advance the scope proximally until the musculotendinous junction of the rectus femoris is visualized. Turn the lens of the scope toward the skin so the light can be seen through the skin. This is the proximal limit of the of the graft and marks the direction of the graft harvest mark the skin at this point. For reference, the width between incisions should correlate with the desired graft diameter. Make the longitudinal incisions and continue them distally toward the patella until contact is made with the bone. The surgeon should note that approximately two centimeters of tendon length needs to be dissected and released. Use a FiberLoop suture to place a tagging suture one centimeter from the end of the graft. This suture is used to maintain tension on the graft during tendon harvesting. The weight of the needle can be used to shuttle the tagging sutures through the cannulation of the QuadPro tendon harvester. Alternatively, a lasso wire can be used for shuttling the tagging suture. Advance the tendon into the tip of the harvester, ensuring the suture is not cut by the harvester tip. Keep steady, gentle tension on the suture and begin rotating the harvester using controlled quarter turns all in the same direction, directing the harvester toward the proximal mark on the skin. Once the desired graft length has been stripped, the QuadPro tendon harvester can be withdrawn from the incision and the graft can be retrieved through the graft cutting window. By grasping the tagging sutures, advance the QuadPro tendon harvester back into the incision. When the appropriate graft length is reached, insert the push rod into the harvester. Keep tension on the tagging suture, and advance the push rod forward to amputate the graft. The adjustable variable size, all in one FlipCutter three guide pin and reamer allows minimally invasive socket creation from the inside out. The FiberTag TightRope implant facilitates attaching single ended grafts to the ACL, TightRope, PT, and ABS implants. Fibertag suture is integrated into the TightRope implant for a strong connection between the suture and TightRope loop. A simplified suturing technique, along with innovative packaging and the new graft clamp graft preparation instrument, make preparing quadriceps tendon grafts faster and more reproducible.

John W. Xerogeanes, MD (Atlanta, GA), demonstrates a quadriceps tendon autograft ACL reconstruction using the QuadPro™ tendon harvester, FiberTag® TightRope® implants, and FiberTape® suture for the InternalBrace™ technique.
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.

A video recording of a surgical technique on a live patient in an operating room setting or a cadaveric demonstration.

Videos - OP-Anleitung

Vídeos — Técnicas cirúrgicas

Videos de técnicas quirúrgicas

Surgical Technique Videos

QuadLink™ ACL Reconstruction Using the QuadPro™ Harvester and FiberTag® TightRope® Implants

application/pdf

A step-by-step demonstration of how a product would (or could) be used in a surgical technique.

Eine schrittweise Demonstration, wie ein Produkt in einer Operationsanleitung verwendet werden würde (oder könnte).

Operationsanleitungen

Demonstração passo a passo de como um produto seria utilizado em uma técnica cirúrgica.

Guias de técnicas cirúrgicas

Demostración paso a paso de cómo se utilizaría un producto en una técnica quirúrgica.

Guías de técnicas quirúrgicas

Surgical Technique Guides

QuadPro™ Tendon Harvester Surgical Technique

The FiberTag® TightRope® implant offers improved performance and reduces quadriceps tendon graft preparation time.1 A FiberTag suture is prestitched onto a TightRope II implant and the GraftClamp instrument is used to hold the tendon and suture card while the graft is prepared.&nbsp;

Reference
1. Arthrex, Inc. Data on file (APT-04275). Naples, FL; 2019.

FiberTag® TightRope® II Graft Preparation

The FiberTag TightRope two implant builds on Arthrex. S legacy of innovation in ACL graft fixation technology by adding optimized features to the revolutionary FiberTag TightRope implant design. The flat tape loop and tensioning strands provide improved strength, feel, and handling. The redesigned cortical button includes a proprietary knotless fifth locking mechanism for increased strength and resistance to cyclic displacement, and allows for precise incremental tensioning of the construct after final fixation. The FiberTag TightRope two implant is available with a preloaded FiberTape suture for the internal brace technique, proven in peer reviewed research to be associated with less pain, improved patient reported outcomes, and a faster and higher rate of return to pre-injury level of activity. Alternatively, the FiberTag TightRope two implant is available preloaded with an additional flipping suture for optimized cortical button deployment. New, shorter locking splices create a shorter minimum loop length to maximize the amount of graft in the socket. A straight tapered needle makes graft suturing smooth and effortless. And an enhanced SutureCast design improves suture management during implant assembly. Mark the graft circumferentially at the desired length of stitching. Load the FiberTag TightRope two SutureCast onto the graft clamp instrument. It's important to fully seat the card into the slot in the jaw of the instrument. The FiberTag implant can be pushed onto the tooth of the graft clamp for further stabilization. Clamp the graft clamp approximately two millimeters from the end of the graft. Pass the improved tapered needle at the marking to provisionally extend the FiberTag implant along the graft. Use the standard FiberLoop technique with two SpeedWhip stitches, working toward the suture card and ensuring the FiberTag implant is captured with each needle pass. After the two SpeedWhip stitches are performed, insert the Insert the needle through the slot in the SutureCast, ensuring the needle passes over the TightRope loop. Place two additional SpeedWhip stitches working back down the FiberTak implant, forming a locking style stitch. Pass the needle into the tissue beyond the end of the FiberTag implant. Cut one suture loop just below the suture. Splice near the needle, ensuring the needle is still attached to the opposite end. Wrap the suture limbs around the graft and tie them securely. Then cut the suture without the needle. Use the needle to bury the knot within the graft. Cut the remaining suture limb flush with the graft. Remove the FiberTag TightRope two suture card from the graft clamp and unclip the remaining sutures from the suture card. Prepare the opposite end of the graft with a FiberTag TightRope two ABS implant in a similar fashion.

Jason M. Scopp, MD (Salisbury, MD), discusses recent innovations in QuadLink™ ACL reconstruction.

Surgeons presenting one or more clinical cases

Chirurg:innen präsentieren einen oder mehrere klinische Fälle

Videos von Fallpräsentationen

Cirurgiões que apresentam um ou mais casos clínicos.

Vídeos apresentações de casos

Cirujanos que presentan uno o más casos clínicos.

Video presentaciones de casos

Case Presentation Videos

QuadLink™ ACL Reconstruction Using FiberTag® TightRope® Implant and FlipCutter® III Drill

Hi, my name is Doctor Jason Skop and today I'm going to talk about innovations in QuadLink ACL reconstruction. Our patient is a 22 year old male lacrosse player who presented with an ACL tear during the diagnostic arthroscopy. He was found to have a repairable posterior horn medial meniscus tear. This was repaired with two meniscus since two implants in a vertical mattress fashion, giving us a stable construct, as you can see here. We then turn our attention to the quad harvest. A two centimeter incision was made at the superior pole of the patella. The section was carried down through the para tenon, which was swept medially, laterally and proximally. Then a ten millimeter double blade knife was used to harvest a central slip of the quadriceps tendon to a distance of 65mm. The graph was then removed from the knee and placed on the back table for preparation. Using the FiberTag TightRope implant, we use an RT on the femoral side and an ABS on the tibial side. Two SpeedWhip sutures were passed proximally through the TightRope and then two passes distally to complete our femoral preparation. This was performed similarly on the tibial side. An internal brace was then incorporated into the femoral end of the graft. We then took the graft compression tubes to take our construct, which was now 10.5mm, and compress it down to a graft of 9.5mm. We then turn our attention back to the knee to begin our tunnel preparation using the femoral six nine guide. We drilled our FlipCutter three and visualized its entrance into the joint. Once the FlipCutter three device was visualized, we activated it and chose our tunnel size to correlate with a 9.5mm socket. We chose a 9.5 socket here, even though the graph was originally 10.5mm. That compression of the graft during graph preparation allows for graft re-expansion later on to improve our fill of our socket. This is also performed on the tibial side. Once the FlipCutter has been activated, our femoral tunnel is created and a shaver is inserted to remove any loose debris prior to passing our FiberStick. The tibial tunnel is created in a similar fashion. The advantage of the FlipCutter three is if my graft size on the tibial end does not match the graph size of my femoral end, I do not need to open up a second FlipCutter device. I am able to simply dial down or dial up to improve my accuracy during tibial tunnel creation. Our graft is passed and our internal brace here is visualized on the posterior aspect of the graft. And here are the patient's final post-operative radiographs. Thank you.

QuadLink™ Graft Preparation With the FiberTag® TightRope® Implant

ACL-Rekonstruktion mit Quadrizepssehnen- transplantat

Implant System, Secondary Fixation with BioComposite SwiveLock Anchor 4.75 x 19.1 mm

Implant System, Secondary Fixation with PEEK SwiveLock Anchor 4.75 x 19.1 mm

RetroConstruction Drill Guide System Instrument Set

Instrumentenset, für RetroConstruction-Zielinstrumentensystem

Femoraler ACL-Zielhaken, AM-Portal, 7 mm Offset

Femoral ACL Marking Hook, AM Portal, 7 mm Offset

ACL TightRope, Drill Pin, Closed Eyelet

Zieldraht für ACL TightRope, 4 mm m. geschlossener Fadenöse

Drill Pin, ACL TightRope, Closed Eyelet, 4 mm

Aguja perforadora, ACL TightRope, ojal cerrado, Ø 4 mm

ACL TightRope, Drill Pin, Open Eyelet, 4 mm

Zieldraht für ACL TightRope, 4 mm mit Fadenöse

Drill Pin, ACL TightRope, Open Eyelet, 4 mm

Aguja perforadora, ACL TightRope, ojal abierto, Ø 4 mm

Drill Tip Guide Pin 3.5 mm x 311 mm

Zieldraht mit Bohrgewinde, 3.5 mm x 311 mm, steril

Aguja guía con punta de broca, Ø 3.5 mm x 311 mm

Drill Tip Guide Pin 2.4 Mm x 311 Mm

Zieldraht mit Bohrgewinde, 2.4 mm x 311.0 mm, steril

Drill Tip Guide Pin, 2.4 mm x 311 mm, sterile

Aguja guía con punta de broca, Ø 2.4 mm x 311 mm, estéril

Guide Pin with Suture Eye 2.4 x 435 mm

Pullout Pin mit Fadenöse, 2.4 mm x 43.5 cm, steril

Guide Pin with Suture Eye, 2.4 mm x 435 mm, sterile

Aguja guía con ojal de sutura, Ø 2.4 mm x 435 mm, estéril

Fio broca com orifício de sutura, 2.4 mm x 435 mm, estéril

Fio broca com orifício de sutura, 2.4 mm

#2 FiberSnare suture, 26" length with 2” closed loop (Black/White)

#2 FiberSnare with #2 FiberWire Braided Polyblend Suture, Black/Whitewith Closed Loop, 26 inches, One End Stiffened, 12 inches

#2 FiberSnare suture, 26" length with 2” closed loop (White/Blue)

#2 FiberSnare with #2 FiberWire Braided Polyblend Suture, White/Bluewith Closed Loop, 26 inches, One End Stiffened, 12 inches

Child (D)

Arthrex bietet eine breite Palette an Produkten für die Fixierung, die im Rahmen unterschiedlicher Knochen-Patellarsehnen-Knochen-Transplantattechniken (BTB) eingesetzt werden können. Zu diesen Optionen gehören die verstellbare Aufhängungsfixierung mit Endlosschlaufe und Interferenzschrauben aus verschiedenen Materialien. Das TightRope-Implantat, das weltweit bei 2 Millionen Eingriffen verwendet wurde1, wurde entwickelt, um die ACL-Rekonstruktion zu erleichtern und fortschrittliche Techniken wie die GraftLink-Technik zu ermöglichen. BioComposite FastThread-Interferenzschrauben, die aus einem bewährten Material bestehen und seit mehr als einem Jahrzehnt klinisch erfolgreich implantiert werden, ermöglichen ein schnelleres Einbringen der Schrauben und einen besseren Schutz des Transplantats.2
Referenz
1. Arthrex, Inc. Data on file (sales data as of September 18, 2018). Naples, FL; 2018.
2. Arthrex, Inc. LA1-0199-EN_E. Naples, FL; 2018.
Bitte beachten Sie, dass bestimmte biologische (PLLA)-Anker und -Schrauben nicht für den Verkauf im EMEA-Raum verfügbar sind.

This animation demonstrates a BTB ACL reconstruction using the TightRope® II BTB implant with FiberTape® suture for the InternalBrace™ technique, BioComposite FastThread™ interference screw, FlipCutter® III drill, and 4.75 SwiveLock® anchor for ACL backup fixation.
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.

BTB ACL Reconstruction With BTB TightRope® Implant and FastThread™ Interference Screw

The femoral socket is prepared in a retrograde fashion using the FlipCutter three reamer and side release RetroConstruction drill guide handle. The adjustable all in one FlipCutter three retrograde drill can accommodate varying tunnel sizes from 6 to 12mm, including half sizes. The guide is placed into the joint and the FlipCutter drill sleeve is inserted down to bone. The FlipCutter three is then drilled into the joint, and the side release drill guide handle is removed. The stepped drill sleeve is then melted into the bone. The FlipCutter three size wheel is used to deploy the tip to the appropriate size, and a socket is reamed to the desired depth. After creating the socket, turn the size wheel back to 3.5 and remove it from the joint while keeping the drill sleeve in place. A FiberSnare suture is then passed through the drill sleeve and retrieved through the tibial tunnel. The revised, streamlined BTB TightRope two preparation card is intuitive and steps are labeled for simple implant assembly. Load the blue passing suture and white tensioning strands into the FiberSnare, and then pull through the femur, leaving FiberTape InternalBrace sutures out of the tibia. Pull the sutures together to advance the button, while maintaining counter tension on the FiberTape and traction sutures. When the femoral bone block is visible in the joint, stop advancing the graft and align the bone block with the femoral tunnel using a grasper or a probe to advance the graft. Pull the tensioning strands one at a time, alternating approximately two centimeters on each side, while maintaining distal counter tension on the graft and InternalBrace sutures. Once the graft is seated, pull firmly back on the graft to check fixation before fixing and tensioning the graft. The internal brace is anchored using a Biocomposite SwiveLock ACL backup fixation system. Using the spade tip drill followed by the 5.2mm tap. The internal brace FiberTape are placed into the eyelet and with the knee in full extension, the SwiveLock is screwed into the drilled hole. The appropriate sized biocomposite FastThread interference screw is selected, and a 1.1mm guide wire is then inserted in the tibial tunnel between the tibial bone block and tunnel wall. The appropriate size tap is then inserted over the guide wire and driven to a depth that approximates the screw length. A FastThread interference screw can then be implanted over the guide wire on the free edge of the bone, plug away from the tendon, insert the screw to the appropriate depth and if necessary, release the slap driver handle to remove the driver. Check fixation of the graft and remove the guide wire. The knee can be tested through a range of motion and with the knee and full extension. The BTB TightRope two can be retensioned to remove any slack in the graft construct.

Justin J. Mitchell, MD (La Crosse, WI), demonstrates a bone-patellar tendon-bone (BTB) ACL reconstruction using FiberTape® suture for the InternalBrace™ technique. Dr. Mitchell explains how to properly assemble the new BTB TightRope® II implant to the graft, fixates the tibial side of the graft with a BioComposite FastThread™ interference screw, and fixates the FiberTape suture for the InternalBrace technique with the ACL Backup Kit using a 4.75 mm BioComposite SwiveLock® anchor.
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.

BTB ACL Reconstruction Using the BTB TightRope® II Implant and InternalBrace™ Technique

We're going to be performing an ACL reconstruction utilizing a Bone-tendon-bone autograft with our BTB ACL TightRope two with the associated internal brace. The TightRope two with the internal brace is prepackaged on this card and gives you step by step instructions on how to complete the procedure. The first thing we're going to do is take our needle out of the number one slot, and pass that through our previously drilled hole in the femoral bone block. After passing our suture, we're going to cut the needle off and we're going to transition to step number two, taking off the free suture which will unravel. And then the free end of this suture is going to be passed through our loop. So after we've passed it through the loop within the bone block, we're going to take the free end of our suture and pass it through the wire loop on the card. One of the tricks here is we can actually fold this over and pinch it so that it's easier to pass. So now that we've got that suture pass through the wire, we're going to hold our pinched end here like I talked about. And essentially we're going to pull this tab out which will allow us to pass our suture. And one of the tricks here is just to kind of hold the end of the card gives you some resistance so you can pull that right through. Once we've got our suture pass through the mechanism we can actually flip our card over. We're going to pick up our trapdoor tab and pinch our side tabs like this, which is going to allow all of the sutures just to come straight off like that. Once we've got all of our sutures off the back of the card, we're going to take the card, and at the bottom everything just opens up, exposing the internal aspect of the card and the button. Once we've got the card open, we can see our button, and we're going to pull our button straight through the card, which will bring all of our remaining sutures out of the card. We can see here, now that we've got our sutures separated, our internal brace strand is coming this way, and the free end of end of our previously passed suture is right here, which is going to allow us even up the TightRope tensioning strands. Now that we've got our ACL tensioning strands, even we can shuttle the sutures through the bone block to ensure ease of passage when we're tightening our final construct. In the event that anything should happen on the tibial side or any of these sutures should break, what I like to do is put a rescue stitch right at the junction of the bone tendon interface with a FiberWire suture, so that we have a rescue suture as we pull through the tibia, just in case anything should happen. So we've got our graph prepared. We've got our tunnels drilled. You can actually see our passing suture coming through the femoral tunnel into the tibial tunnel. We've got a full socket in the tibia, because we're going to use a FastThread screw to secure the tibial side. And now we're going to pass our BTB TightRope two up through the tibial tunnel and secure it over the lateral side of the femur. So you can see here our sutures are passing coming through the femoral tunnel. So now we see our button being pulled in. We can see it transitioning to the to the femoral socket. And I'm actually going to switch to a medial view so I can see the button go through the tunnel and flip on the lateral cortex. You can actually see the button coming right into the femoral tunnel going into the aperture of the femoral tunnel. We're going to pass that button through the hole onto the lateral cortex. And what the assistant is going to do is actually pull tension on the internal brace strands, which is going to help us keep tension on the button so that it will flip over the lateral cortex. So now we feel that we've got the button flipped. We're going to give a little tension on the sutures through the tibial tunnel. You can see we're giving a little tension there. And we've got that button nicely flipped against the lateral cortex. So you can see now we've got our sutures passed through the tibial tunnel and into the femoral tunnel. The nice part about this is I was able to use the FlipCutter to create the femoral tunnel. We don't have to be parallel with our portals in this situation. And so the nice part about the FlipCutter is it gives a very smooth aperture and allows for easy passage of our sutures when we're pulling our bone block in. Now we're going to have our button against the lateral femoral cortex, and it's going to going to allow for circumferential fixation of our graft and our bone block, which is different from having a screw fixation, which actually takes a little bit of the surface area away from the bone block. So now we're going to start pulling this in and putting our bone block into the femoral tunnel. So one of the things you can do is this is coming in is give a little bit of slack on these sutures using a probe. And you can see our bone blocks starting to come in. This is allowing us to get things in an appropriate trajectory. So I'm using our KingFisher here to direct our bone block into the correct position so that it will easily slide into the femoral tunnel. So now as you can see, we've got our graft all the way into the femoral tunnel. You can see our purple mark right at the edge there. So we've got our bone block right to the aperture of the femoral tunnel. We've got the remainder of our graft in here. And you can see down in our tibial tunnel we are just nearing the purple mark. So the edge of our bone block you can see our rescue suture there. So we've got this very nicely past. And now we're going to work on the tibial side of the graft. So now that we've got everything past we're turning to our tibial side and we and we can actually see our InternalBrace sutures coming out the tibial tunnel. Right here. And what we're going to do is independently fixate our InternalBrace sutures just distal to the aperture of the tibial tunnel. So the first thing we're going to do is create our drill pilot hole. And at this point, the knee is in full extension. So now that we've drilled our pilot hole, we've got our new 5.2mm tap which comes in the ACL backup kit. The nice part about this tap is that the thread pitch is perfectly aligned to the 4.75mm SwiveLock, and using this allows for placement of that swivel lock in harder tibial bone and can accommodate an associated FiberTape. So we're tapping here using our 5.2mm tap. So with our tap in place, we've already preloaded our 4.75mm SwiveLock. And this helps make sure that we do not lose our pilot hole. We've now got our SwiveLock secured against the anteromedial tibia, such that our internal brace is independently fixed outside of our bone block. And actually, this FiberTape is actually on the back side of the bone block so that when we put in our screw, it's not abrading against the screw. [00:06:29] Yeah. Yeah. Sorry. Yeah. Good. So now that we've got our internal brace fixed, we are keeping longitudinal tension on our sutures that are within the tibial bone block. You can see our rescue stitch is independently clasped on this side, just in case we need it. And I'm going to insert our guidewire right over the superior aspect or the anterior aspect of the bone block. We're going to insert our tap over the anterior aspect of the bone block to allow for passage of our FastThread screw. I can see the bone block right at the aperture of our tibial tunnel. So I know we've got good graft tunnel match. Now that our tapping is complete, we're going to insert our FastThread bio composite screw over the anterior aspect of the graft in line with the tunnel. And you can actually hear that good fixation there. So one of the really nice things about this screwdriver is that it actually has a self slap hammer mechanism so that you can unlock the screwdriver, back it off, and actually pull the screwdriver off easily. As we know, these screwdrivers can sometimes get stuck in these screws, and it's easy to just back it out with that self slap hammer mechanism. So the really nice part about using the TightRope two system is that after we've fixed our distal tunnels, we can actually retension the femur to make sure we've got all the creep out of the graft. So if we pull on our femoral sutures, we should be able to get a little bit extra out of the tensioning system. So with our knee extension, we're just going to pull a little bit of creep out of this system. And you can see that graph moving ever so slightly taking all the remaining creep out of the graft. And in the end we've got a very nicely situated bone-tendon-bone graft appropriate tension. And our reconstruction is complete.

BTB TightRope® II Implant

Imaging and Resection

James E. Voos, MD (Cleveland, OH), demonstrates an ACL reconstruction using the Synergy Vision™ imaging system and the Pano™ scope.

Animations demonstrating the features and benefits of a specific product.

Animationen, die die Funktionen und Vorteile eines bestimmten Produkts demonstrieren.

Produktdemonstrationen

Animações demonstrando os recursos e benefícios de um produto específico.

Vídeos de demonstração de produtos

Animaciones que demuestran las características y beneficios de un producto específico.

Videos de demostración de productos

Product Demonstrations

ACL Reconstruction Using the Synergy Vision™ Imaging System

Hi, I'm Doctor James Voss from University Hospitals Cleveland. Today we're going to talk about using the SynergyRF vision NanoScope switching from 30 to 70 degree visualization in both a diagnostic arthroscopy. Also, in referencing our ACL reconstruction, allowing us to visualize our ACL footprints for precise tunnel placement. The NanoScope allows for the ease of navigation, transitioning from the 30 to 70 degree arthroscope without having to change the lens, allowing us to be more efficient and more precise in tunnel placement. We'll start with our standard diagnostic arthroscopy of the knee, beginning in the patellofemoral joint with our standard 30 degree view, being able to visualize both our patella and trochlea. The unique part of the SynergyION NanoScope is switching to our NanoScope view, allowing for that broader visualization of the entire patellofemoral articulation. Looking for articular cartilage lesions and in cases of patella instability, being able to assess the depth of the Of the trochlea. The medial facet. Patella chondral injuries as well as the lateral trochlea. Injuries all in one view, giving you a much more comprehensive view of the level of pathology and easily transitioning to the 70 degree and the 30 degree scope allows you to maneuver around the joint for your typical diagnostic arthroscopy. As we continue our diagnostic scope, we get our standard 30 degree view by moving to our NanoScope allows us to get a much more global view of the entire condyle assessing for articular cartilage lesions. Again, moving over to our notch. And we'll go back to our standard 30 degree scope, again showing how easy it is to transition with one push of a button going into our lateral compartment, being able to assess the route. And again, getting that much more global view of the articular cartilage surfaces and global view of the meniscus. Coming over to our medial compartment, again, able to visualize with our standard 30 degree scope and without having to change again. Moving to that Pano view, assessing the entire articular cartilage surface, as well as being able to see back towards the root. One of the most versatile applications of the vision, NanoScope, is assessing the ACL footprints, both on the femur and on the tibia. Here we have our standard 30 degree arthroscopic view showing our tibial footprint and looking around the corner to our femoral footprint. Typically, at this point in the case, we would switch to a 70 degree arthroscope, which takes some additional time, as well as the additional needing to open a 70 degree lens here, just with the push of a button switching from the 30 to the. The Pano view allows you to really visualize the entire ACL footprint. Your 70 degree scope brings you around even further. So that 30 degree view all the way over here where you can't quite visualize your footprint, allows you to have that direct visualization. Now you have much more accurate footprint assessment, much more accurate tunnel placement. You're able to visualize the back wall as well as the entire anatomy of the ACL. So we'll show more of that here later as we're drilling our tunnels. And as we've published previously utilizing the 70 degree scope. And now the NanoScope view allows us, as we're drilling our femoral ACL tunnel again, to have accurate tunnel placement as well as accurate depth, being able to measure both the front and the back of our tunnel to assure the appropriate depth. So we don't have any bone plug and graft mismatch. In addition, coming down to the tibial footprint, we'll go back to our standard 30 degree view, which we typically see. And often it's hard to see ACL material graft material flipped over here in front of the meniscal ligament. Now with our NanoScope allows for that easy view all the way in front to be able to see the anterior horn of our lateral meniscus and any ACL material that may be flipped forward that can cause a Cyclops lesion. This also allows for that full assessment of very accurate tunnel placement, as we place our guide to ensure that we're very accurate, again with our 70 degree scope having that similar view. If we look again, our angular view with our 30 degree scope doesn't quite give us that full perspective. Now with our NanoScope allows again visualizing the entire footprint much more accurate placement of our tibial guide. Right here we're preparing to do our notch plasty again with our standard 30 degree view, where we would prepare our notch plasty in efforts to see the back wall. And with the standard 30 degree scope, there is often the need to do a larger notch plasty than you would otherwise plan to do in order to see the back wall. By utilizing the NanoScope and the 70 degree view, now we can see the See the entire notch here, the wall on Foss allowing us to take the appropriate amount of bone. So now we can protect the ACL graft from impingement, but avoid excessive bone resection. Now, utilizing the shaver here allows us to continue the visualization without having the excessive suction with the fat pad collapsing on you and again with the. Utilizing the NanoScope allows us to be much more precise with our notch plasty again, taking just the appropriate amount of bone here to pass the graft without impingement. Great. So again, we can see all the way to the back very easily, having a nice smooth notch from front to back. And again, if we sit here with our NanoScope, let's go back to our 30. We show the difference of how you're looking down the wall versus straight at the wall. You have a much more precise view, right? Here we are after removing our ACL to breeding back to our tibial and femoral stumps, our notch plasty is complete. This is one of the areas where the NanoScope has the most versatility in femoral tunnel placement. And here with the typical 30 degree view as we're feeling around the back wall, attempting to make that 70 degree or that seven millimeter measurement here off the back wall, it is very challenging with our depth perception to have accurate tunnel placement. So one of our most common errors in ACL failure is poor tunnel or improper tunnel placement. So using the NanoScope to increase that accuracy can increase the outcomes of our ACL reconstructions. Now by switching to our NanoScope allows us to have a much more accurate visualization and depth perception from our back wall, measuring those seven millimeters anterior to get our most accurate tunnel placement to avoid that tunnel mismatch. One of our other key benefits of using the NanoScope. Now that we can visualize the footprint accurately, it avoids the need to have to hyper flex the knee during the surgery, which can limit your visualization. Now that we have our ability to see the entire footprint utilizing our flexible reamer, now we can place our tunnel accurately, leaving our knee at that 90 degree position, which frees up hands and space in the operating room. So now we can drill our tunnel here much more accurately. Again, looking right at the face of the footprint here. And again, with the NanoScope, just with a slight rotation of the hand, gives you much more global view of that pin entry. Again, visualizing your back wall throughout the entire process. But here now with our pin placement, as we've published previously, the difference from the 30 to 70 degree arthroscope here now, using our NanoScope allows us to look from the top down, viewing our pin placement, getting very accurate measurements. And as we place our reamer, we'll have even more accurate measurements as to the front and back positions of the tunnel. An additional advantage of the NanoScope is being able to see the reamer pass through the medial portal and past the medial femoral condyle, to avoid any scuffing or injury to the medial femoral condyle, again allowing that increased visualization to avoid any iatrogenic injury. Now, as we have the reamer in again, a very versatile and one of the most advantageous parts of using the NanoScope is as we drill our femoral tunnel. We're typically referencing here distally to get our measurement. As we've recently published, with our utilization of a 70 degree scope and the top down view, the NanoScope allows us to measure not only the front of our tunnel, but the back of our tunnel. And as recent studies have shown, coming through the medial portal, the tunnel entry can be oblique or an ellipse direction where your distal portion of your tunnel may measure deeper than the posterior portion of your tunnel. So measuring off of the back wall gives you a much more accurate depth of your tunnel. That way, your bone plug you avoid any tunnel and bone plug mismatch. So unique advantage of the NanoScope is able to visualize the posterior portion or the deep portion of your tunnel, so you have accurate depth. Utilizing our Pano NanoScope again, our typical view straight on being able to look over the top and measure off the back wall. Now as we continue to insert our reamer, we know exactly the depth, both the distal and posterior ports, portions of our femoral tunnel so we can continue on. Here's a nice example of being able to measure. Our front portion of the wall appears to be about 21, whereas the back portion of the wall is that 19. So if we really want accurate placement, we can measure off the back. We'll go just a few few more millimeters getting there to 22. Perfect. Now we know the back wall is that 22. Again, for much more accurate tunnel placement. This is very important in our primary ACLs, but even more important in our revision surgeries where tunnel depth and protecting the back walls is most important. Here we are preparing our tibial tunnel guide pin placement. We've cleaned off the ACL footprint with our typical 30 degree arthroscope view utilizing our references of the Of the tibial spines, the anterior horn of the lateral meniscus, and the intra meniscal ligament. So our typical 30 degree view gives us that slightly oblique view. By switching to our NanoScope gives us a much broader view, allowing us to more easily visualize all of those frames of references, also allowing for better depth perception and placement of our guide. Again, seeing in one view our entire meniscal ligament, our anterior horn of our lateral meniscus and our tibial spines, allowing for us to triangulate for a very accurate guide pin placement. In addition, it allows us to look directly at the pin coming in with that bird's eye view versus a more oblique shot, again confirming our more accurate pin placement. Our tibial tunnel has been prepared with a ten millimeter cylindrical reamer. Here's our typical 30 degree view where we can see the tunnel in particularly the back wall. It's a little bit harder to see that interior wall to see circumferentially. By switching to our NanoScope now allows us to visualize the tunnel Circumferentially 360 degree view. This is important in our ACL tunnel drilling. If you're using an all-inside technique to get a sense of the depth of your tunnel. In a revision setting where you're looking for circumferential bleeding, bone in removal of prior graft material, or assessing where cystic formation or tunnel widening may be, it also allows, in those circumstances, utilizing a bone dowel or needing accurate assessment of tunnel depth for us to visualize very accurately and all planes circumferentially the depth of your tunnel. Here's our standard 30 degree view of passing our button for our ACL TightRope again 30 degree view. Attempting to look up the tunnel to watch the button flip by switching to the NanoScope scope allows you to look directly up the tunnel. Circumferential view, watching the button pass up the tunnel and allowing for that safe visualization of flipping of the femoral button. As we prepare to pass our bone plug, now having that direct visualization of the button flipping as well as your tactile feed pulling back to know that your button is flipped. So dual confirmation of both. Direct visualization of the flipping of the button, as well as your tactile pulling back to assure that the button has flipped on the far cortex. And in particular, referencing our study before from the 30 to 70 degree scope. Now we can see the back wall assure our bone plug is flush with the back wall. Very accurate bone plug placement. Okay, now we're in our Pano NanoScope mode, where we can see our entire ACL construct from anterior to our tibia to make sure that there is No ACL, stump or debris all the way up our tunnel. Now we've tensioned our our internal brace here posteriorly so we're a nice, good tension. Our GraftNet tension. And we're going to refine our tensioning of the graft here in extension. So we'll we've done our cycling. We'll do our final tensioning here in full extension. And again with the NanoScope allowing us to look all the way up the tunnel, getting a full fine view. Excellent. Seeing that last little bit of tension here in our graft. Again, in one view, being able to visualize from our tibial tunnel all the way up into our femoral tunnel, accessing that nice tension here in extension, completing our ACL reconstruction.

This animation highlights the ACL TightRope® implant’s successful clinical history,1 introduces the TightRope II implant, and explains the new implant’s unique features and benefits.
1. Arthrex, Inc. Data on file (as of July 10, 2018). Naples, FL; 2018.

Introduction to the TightRope® II Implant

The ACL. Tightrope implant revolutionized suspensory graft fixation by allowing intraoperative adjustability of the graft position with a single implant, eliminating the need for multiple size options. With an innovative design compatible with several graft types and socket creation techniques, the implants reliability has been proven with a history of nearly 2 million implantations and supported in hundreds of published studies. Newly redesigned, the ACL TightRope two implant represents the next evolution in suspensory graft fixation for additional strength. The TightRope two loop is constructed of a flat tape, creating a broader suture graft interface. Flat tensioning strands provide improved handling during tensioning. Engineered for precise graft tensioning, the TightRope two implant allows for incremental tensioning of the construct after final fixation. The redesigned cortical button now incorporates a proprietary knotless fifth locking mechanism for increased strength and resistance to cyclic displacement. Versatile and innovative. The TightRope two implant is compatible with multiple graft options and all existing socket preparation devices, including the FlipCutter three drill, as well as flexible and low profile reaming systems. The TightRope two implant facilitates improved biomechanics and circumferential graft to bone healing in both femoral and tibial sockets, with significantly improved graft integration and less tunnel widening compared to screw fixation. The preparation card for the BTB TightRope two implant is streamlined for a faster, easier and more intuitive graft assembly. Tightrope two implants are available in PT and BTB configurations, preloaded with an additional flipping suture or with an included internal brace implant, as well as ABS and open ABS options. The Arthrex TightRope two is another example of Arthrex continued commitment to product innovation and helping surgeons treat their patients better.

A document containing information about Arthrex products and product lines.

Ein Dokument mit Informationen über Arthrex Produkte und Produktlinien.

Broschüren

Documento contendo informações sobre produtos e linhas de produtos da Arthrex.

Brochuras

Documento que contiene información sobre los productos y líneas de productos de Arthrex.

Folletos

Brochures

FastThread™ Interference Screws A New Turn in ACL Fixation

James P. Bradley, MD (Pittsburgh, PA), demonstrates a BTB ACL reconstruction using BioComposite FastThread™ interference screws and the FiberTape® button for the InternalBrace™ technique.&nbsp;
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.&nbsp;

BTB ACL Reconstruction Using BioComposite FastThread™ Interference Screws and the FiberTape® Button for the InternalBrace™ Technique

Good morning. I'm Jim Bradley from Pittsburgh, Pennsylvania. I'm going to talk to you about the internal brace ligament augmentation button that can be used with either allografts or autographs. So we've already made our tunnels for the BTB ACL. We're going to use a FiberSnare that you can put through the needle, which we're going to pass through the tibia and the femur, allowing you to pass both the sutures from the BTB and the internal brace at one time. So we push this through. We're going to pull it out and capture the FiberSnare. So we're going to grab the FiberSnare out of the knee, bring it out through the tibial tunnel. So we're going to load the BTB passing sutures and the internal brace passing sutures through the through the FiberSnare both at the same time. So now you can obviously see that outside our tibia we have our BTB graft and our internal brace augmentation device through the same time. So now we're going to take the blue number five and independently pass that first with our internal brace augmentation device. Now we have to flip that. Now that it is set just by toggling those sutures you can set the device. Now it's set I can't pull it out anymore. So now we're going to bring the graft into the femur and fix only the femoral end. Perhaps in there's the hole. The internal brace is behind the bone. Patellar tendon. Bone graft. So now we're going to tap for the FastThread screws. So this is a seven by 20. Fastthread ACL screw. Just run it right up after you've tapped and run it right over your guidewire and engage the femoral foam plug of the BTB graft. Sometimes it gets stuck like that. So what you actually can do is you can unhinge it here, and you can use this almost like a slap hammer to get this off the screw like that, rather than try to pound it out. There's the screw. The internal brace is behind the construct where I want it. And now, in full extension, we're going to fix the internal brace first in full extension, and then we'll fix the tibial side of the BTB graft. What we have here is a 4.75 drill bit for the swivel lock. You want to go right above the Pez. Remember the Pez is sitting right there. So and if you just get a little bit above it there's really good cortical bone right there. And you must tap this bone because it's really hard. This is a 5.2mm tap from the ACL backup kit. Put your SwiveLock at the orifice. Full extension. You tap it in. The reason you use A52 tap is because you have to accommodate these two fiber tapes. I put it flush with the cortex, and once I feel that it's flush with the cortex, I then remove the swivel lock. And now you can cut your fiber tape. And now it's time to fixate your graft. So once again we're going to tap for our FastThread ACL screws. The leg based on the patients whether they're a hyperextended or they're not. We typically do it in full extension also, especially if they're hyper extenders. So this is my biocomposite FastThread interference screw for ACL bone BTB fixation. So once again one of the unique features of this once you get it to the cortex is you can use this as a slap hammer. It'll slap it out for you so you don't have to use your mallet. So this is our full internally brazed BTB construct. And you notice that the internal brace is posterior to the graft. Utmost importance. You always fix the internal brace in full extension. So my post-op protocol with no involvement of the Menisci is this patient is in a brace, their full weight bearing on crutches. The crutches end the end of the first week. The brace ends at the end of the fourth week. They're on a bike by the sixth week, and they're jogging by three months is the typical protocol.

BTB Autograft ACL-Rekonstruktion

ACL InternalBrace Ligament Augmentation Button

ACL InternalBrace Ligament Augmentation mit Button

ACL InternalBrace Ligament Augmentation Button

Botón de aumentación de ligamento ACL InternalBrace

Die GraftLink-Technik ist das Nonplusultra bei der anatomischen, minimal-invasiven und reproduzierbaren ACL-Rekonstruktion. Die Anwendung des FlipCutter III-Bohrers in Verbindung mit anatomischen Bohrlehren ermöglicht eine unabhängige Erstellung von tibialen und femoralen Sacklöchern in „Retrobohrtechnik“, wobei die Kortikalis erhalten bleibt und dadurch eine maximal stabile Fixierung gewährleistet wird. Dank der femoralen und tibialen TightRope-Fixierungsimplantate mit dem proprietären 5-Punkt-Verblockungssystem ist die GraftLink-Technik im Hinblick auf die Reproduzierbarkeit das Nonplusultra bei der ACL-Rekonstruktion.
<ul>
 <li>Anatomisch: Die unabhängige Erstellung des tibialen und des femoralen Bohrkanals mit dem FlipCutter III-Fräser und / oder mit Low Profile-Fräsern ermöglicht die ungehinderte Platzierung des ACL-Transplantats.</li>
 <li>Minimal-invasiv: Begrenzung der Präparation von Weichteilgewebe und Förderung des Erhalts von Knochen und Periost durch Erstellung des Bohrkanals mit dem FlipCutter® III-Fräser.</li>
 <li>&nbsp;Reproduzierbar: Das GraftPro-Transplantatpräparationssystems vereinfacht die Transplantatpräparation. Das schräg zulaufende Transplantat und die einstellbaren ACL TightRope II-Buttons erleichtern den Transplantateinzug, die Feinregulierung der Transplantattiefe und das Spannen des Transplantats von femoral und tibial.</li>
</ul>
Die InternalBrace-Operationstechnik dient zur Unterstützung der Primärrekonstruktion und soll nicht die Standardversorgung mittels biologischer Augmentation bei einer Primärrekonstruktion ersetzen. Die InternalBrace-Operationstechnik ist nur für die Weichteilgewebefixierung am Knochen bestimmt und ist nicht für die Knochen-Knochen-Fixierung zugelassen.

Patrick A. Smith, MD (Naples, FL), demonstrates the GraftLink® technique using a TightRope® II RT implant with FiberTape® suture for InternalBrace™ technique.
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.

GraftLink® ACL Reconstruction Using TightRope® II Implant for the  InternalBrace™ Technique

So I'd like to first show the new packaging for the TightRope two. Very convenient. Much smaller than before. And we've got both our T version with the button attached and the ABS attachable button system. And conveniently, the sutures are all packaged together with a quick flip. Everything comes undone. The features of TightRope two. Here we have both an RT version with a button attached and the ABS attachable button system without the button attached. First thing I want to point out is that it's taped now instead of suture, which has several advantages. One is it's softer and more protective for where the loop of your graft is here for fixation. And plus the tapes are much easier on your fingers. So you don't necessarily have to use the tension handles to get your good tension. In terms of the TightRope two, this particular version comes with the FiberTape already attached for the internal brace. The other big advantage of TightRope two is the improved stability of the construct. There's a fifth point of fixation, and I'm going to show you that here. I'm going to back up the tape a bit. You can see that there's an extra loop where the TightRope passes underneath the loop here. And that lock of that TightRope tape right there really improves the overall strength of the construct quite a bit. Two new features. Graftpro that are very helpful make things more convenient for us. And here for the button holder, as opposed to the past where you had to hold this. Now there's a little locking mechanism. Then similarly on the tibial side with the buttonhole here, same thing. You have a locking mechanism, so you free up. If you use a no button abs you just ring around the cleat. If you want a button on the tibial side, you can load it the same way and bring it back up to unlock it. So we're going to demonstrate GraftLink prep for you with a quadruple semitendinosus. Here we're showing the E-ZPass now of our TightRope RT button on the side. You can see with our new system, we just locked it, so and now we unlock it and hold the button in place. So this is the TightRope RT. It has the tape again. As I mentioned, we already have the FiberTape loaded as our internal brace. This is our passing suture. So this is the femoral side. So here on the tibial side we're going to use the ABS attachable button loop system for preparation of graft. You can see the loops pretty long. So it's very easy to just pull the shortening strands here. And you can decrease the loops like this. Make it a little more convenient a little smaller. And so now we're going to anchor it on the cleat to get our fixation, to be able to pass the graft and create our construct. So we just pull that it locks in. So here's our hamstring tendon. Generally my minimal length is 270 with all-inside technique which I'm going to demonstrate today. Typically your total graft length ends up around 65mm or so. So you don't have to have that long a hamstring. But what happens is frequently the harvest is 300 310, but allows you to freshen the edges and save the best tendon for that 270 distance. We have to start with quadrupling our tendon, so we pass through the tibial side first, and then we come on the femoral side, top down on the femoral side. Then we're going to do is one end of the graft is going to pass back through on the tibial side to meet the other end of the graft. So there you can see now I've got my two ends together. And I'm going to demonstrate a continuous loop technique today. So here's our quadruple graft. So I take A20 suture to suture these two limbs of the graft together pass underneath here to the other side and suture this side together in the same way. So that's three passes now. Then I just tie these suture. So I've linked it for a continuous loop. We like to bring our sutured end in the middle of the graft toward the tibial side. So we'll put a little tension. So you can see I'm just bringing that suture part to the inside. So now you can see it's quadrupled. I've buried the suture on the inside. The next thing we're going to do is I'm going to pass my internal brace between the two outer limbs of the graft. And essentially it buries the internal brace on the final construct. That's what I do, is I pass one end of the tape through this limb, and then the other end of the tape through the other outer limb. In this fashion, there's my IB construct. Now we're going to suture or link the four limbs of the graft together. And we do a wrap around cerclage type suture. The key feature with the internal brace, the way this is done is it's totally independent. So a helpful technique for making the graft is to pass a pickup between the middle. And that allows you access to better pass your needle. With our number two FiberWire suture the outer two limbs first of the graft toward the tibial side, avoiding the loops. And then I'll go through all four with my next pass with the needle. So now we pass that through. And then we'll cerclage it. I like to wrap it around three times and then we'll tension it. So once that's tightened now then I just tie it. We just cut the short strand above the knot. And then we can additionally bury the knot by passing through the graft here, making sure to avoid my tape. If you pull this you can pull the knot down. So that buries that knot. We can still move our tapes. The other thing is we have very little tension on the graft at this point. I then go ahead and increase my tension to about 75 Newtons. So here's our final construct quadruple Bio-Tenodesis GraftLink with the FiberTape InternalBrace passed independently through the femoral button. It's going to measure just about 69mm. So here we're sizing the graft and that's ten millimeters. So I do utilize the compression tubes on all of my soft tissue grafts, whether it be a GraftLink semitendinosus or a quad graft. Because I can usually compress a half to a millimeter in size. I measure ten millimeters on the graft with my preliminary measurement. This is a 9.5 compression tube. Got the little locking handle. Makes it easier to hold. So what you do is you pass your loop grasper through the smaller end of the tube. We'll take the graft off the GraftPro, and then we'll just simply grab our sutures with our loop, pull them through the tube, and then bring the graft in. So that's fairly snug. 9.5 I'm pulling pretty hard here, but you get the water out of the graft. Now you can see I'm totally seated in the nine five two and that's pretty tight. So for this case we'll drill A95 femoral socket nine five tibial socket. And sometimes you can go down maybe one more half size. But I think this half millimeter for this graft is what we need. This is a left knee. We're going to do a GraftLink ACL reconstruction with internal brace. I've cut out the ACL. We use the six nine guide on the femoral side. We come through the lateral portal because you can view from the medial portal. And one big advantage of the six nine guide is you can easily see it 90 degrees of flexion. You don't have to hyper flex the knee. So I'm going to position the six nine guide. The outer diameter is nine inner six. Our graph is nine five. So we've got a good idea of where this graph is going to sit. This is single bundle construct for me. And I'm a little bit more toward the Am bundle isometric. So I'm going to position the guide right where I want it. Toward the back here usually I leave about 1.5 to 2mm from that posterolateral position of the condyle. So what we're going to do now is lock it in place. Oops. So we double check our position, make a little stab blade through the IT band. Sorry. So we've got our six nine guide in place here. Good position on the side of the joint side. We've brought our guide sleeve down through the IT band down to bone. So now we're going to drill our FlipCutter three. Should come out right in the center of the six nine guide. So there we are. Disassemble our guide. There's our pin. So now we're just going to open our FlipCutter 3 to 9 five matching our graph diameter. Okay. So there's our femoral socket drilled to a depth of 27. Grab our FiberStick passing suture and dock that on the femoral side. So we've got good position They're on our side. We have our aiming device here through our Am portal. Got a little stump of the native ACL right there. Here's the anterior horn. Lateral meniscus. So we're going to position right like that right out in the stump here. Make a little incision. Okay. So now we're going to drill our FlipCutter three. Unlock our guide. Tap in our tibial guide sleeve seven millimeters. Open up our FlipCutter goes in as a 3.5 diameter pin. Open up to 9.5 to match the graft. There's our TigerStick now on the tibial side in our tibial socket. We have our passport cannula in place. So that's a good position on our tibia. Here's the anterior horn lateral meniscus. So that's a good spot. Here's our femoral socket. Good position. Retrieve my femoral shuttle suture. It's important. On the tibial side, we pass Ask the no button loop with a little cinch suture. That suture right there is going to pull the loop down that protects the shortening strands of the TightRope two with the tapes there. So this is just a shuttle suture that will go with the internal brace on the tibial side. We've pulled our femoral shuttle suture out the passport. So we have our passing suture which is blue for the TightRope two and the two shortening tapes. So we pull that across. So now here's our graph that's come out of the compression 95 tube. We're going to mark our graph two ended up at 68. We just measured it at 68 is where we plan on having 23mm of graft in the femoral side. There will mark right there at 23. And the intra-articular distance is 20. It's never more than usually 22. This is a small knee. So mark 20 from that point. So that leaves us 25 in the tibia. Then we're going to mark where we expect our button to flip. We measure the interosseous distance at 37. So if we take our button and hold it lengthwise. Mark from that point 37. So that's what we expect to see the the button flip on the femoral side. So that's the interosseous distance of the femur at 37mm measured from the back end of the button. Because the button goes through the whole lengthwise. So we want to know that distance where the back end clears the femur. And that's when we should feel and see the slippage. So now we're going to pass our graft through the passport cannula. In the medial portal we have our femoral shuttle suture. Here comes our button. Now I'm going to come in with the scope behind it. Watch our button. Come into the femoral socket and flip it on that femoral hole. You can see the hole there. There goes the button. There's our mark. So we have a couple more millimeters to go. And that's when we should see it flip. So one advantage of the independent internal braces. Remember the internal braces through the femoral button? We just flipped it on the lateral cortex. So we pull hard on the on the internal brace you can see the femur moving. So what this does it really seats that button. And on post-operative x rays the button sits flush on the cortex because you're reducing the button right down by pulling on the internal brace. So another advantage of the internal brace. So we're hoisting the graft up into the femur to our mark which is 23. So we're going to pass the graft into the tibia. Next take our loop suture here. So here we're passing the two ends of the internal brace and the loop suture which has the shortening strands that will pull the graft into the tibia. So bring the two shortening strands out. And we'll take off that loop. So now we'll just pull the graft into the tibia. So there's our graft. So now let's show you the fixation. Okay, so the first order of business is we put the 14 millimeter ABS button on the no button. So we're putting the ABS button here which is 14mm. Now I like this button because it has two holes. And through those two holes I pass the internal brace. So one IB and the second. So now what we're going to do is I'm going to fix the internal brace first. But to do that I like to bring the shorting strands bring the table button down to bone here. I do this in full extension. So I'm going to do here is I'm not tightening the tibia. I'm just going to bring the button down to the tibia here. I keep my length about the same. So here's our abs button. Here's our two tapes for the TightRope two to secure the graft in the tibia. But I'm going to do that second. Here's where I pass the two ends. The internal brace through the two button holes in that ABS button. Again this is 14mm. It's very important. When we fixate the internal brace I fix the internal brace first. I do that in full extension or full hyper extension, but I do. So I want to make absolutely sure that the line of the InternalBrace fixation doesn't compromise my ability to tension the tapes. So you wouldn't want to put the button over this way, because that could constrict the tape tightening for the tibial fixation. So we want to be in line so that these two tapes are free on the button so I can tension them. Second. So I see my position there. So I'll drill a hole in the tibia about a centimeter half distal to the button. This bone is hard. This helps. This is a new 5.2mm tap bit oversize to help with that 4.75 SwiveLock, which is what I fixed the internal brace, but you have to tap this bone. So I've taken the tension out of the two tapes. We're going into full extension. Here's my 4.75 SwiveLock anchor. Find my hole. And this is self tensioning. You just let go of the tapes and secure the SwiveLock. Hold the paddle here. That good squeak. So that's the internal brace fixed first independent of the graft. So our SwiveLock is down. We'll tap this off. Take out our safety suture. So here's our fixation. I'm going to cut my tapes for the IB. But again you can see that I've left room to be able to tension the tibial into the graft. So there's no constriction by the tapes. That's really important. So again in full extension I'm going to tension our graft on the tibial side. And then we'll cycle the knee. I like to cycle the knee 20 times at least. So after I cycle the knee I like to retension the graft. So we use these tensioning handles which give you more force to apply those first on the femoral side. Basically just put a wrap around the middle of the slot in the handle. Again I go into full extension. I don't want to over constrain the knee. And this graft will be tight. And I don't want to put it in flexion and risk the patient losing full extension. So now I'm on the tibial side again. The knee is at full extension. So now I use the handles here to tighten the tibia one more time. So again re tensioning. The nice thing about the TightRope two with that special, that special fifth locking mechanism, you don't have to tie the tapes here to the button. Now we'll look at the final construct. But what I want you to notice here is one of the limbs of the tape. And see the tape is loose in flexion. We put it in full extension when we fixate it. It's a really important point. This is a seat belt. It's going to function at high loads. When it's when stress comes off the graph the tape kicks in. That's a really important point. You can see here full extension. We don't do a notch Plasty. You can see now the tape tightens up in extension there. It's tighter flexion. And then now you can see the tape will loosen a little bit as we flex the knee. There's the looseness of the tape. As we bring it into extension. It starts to tighten and pulls my hemostat my probe off. So there it is. Tighten extension now. So that's a nice GraftLink quadruple semitendinosus.

GraftLink®  ACL Reconstruction  With ACL TightRope®  II Implant  for InternalBrace™ Technique

Patrick A. Smith, MD (Naples, FL), demonstrates the GraftLink® technique using the InternalBrace™ procedure. Dr. Smith explains how to properly load the ACL TightRope® RT implant with FiberTape® suture for the InternalBrace technique.
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.

ACL GraftLink® Technique Using the InternalBrace™ Procedure

The first thing we need to do is load our long FiberTape seen here through our button. And for the independent InternalBrace, we're going to use the double loaded TightRope as seen here, which has the number two TigerWire passing suture. And there's also a number five through this second hole here to pass the FiberTape. We're first going to remove the number five suture. So now what we're going to do is we're going to pass the stiff end of the FiberTape through this hole alongside our mechanism. So conveniently the FiberTape has a stiff waxed end. And so we can pass it through Alongside as seen here. So we want to make sure that there's two passes through the button with the FiberTape. And we want to make sure that we have it oriented properly, so that the two free ends of the tape are going to be on the tibial side. We take the other stiff end, which is much easier through the vacated hole from the passing suture that we removed. Then we're going to even out the tapes. So now we have our independent InternalBrace passed through the femoral suspensory TightRope fixation button. And the free ends will be on the tibial side here. Now we prepare the graft. We've created our four stranded GraftLink construct. And before we're going to do the suturing, we want to go through this important step of how to pass the tapes. And when done this way, upon completion, the tapes will be inside the construct. It will not be visible at the end of the procedure when the graft is in place in the knee, which is nice. We have four strands of the graft. So if you take a hemostat and come between the outer on one side and the inner construct and pass one end of the tape as seen here, and the same thing on the other side through the outer limb of the tendon, from the central part of the tendon, pass the other side, and then we'll put our linking sutures on each side. The tapes will still slide as we'll show you. And then upon completion of the construct, the tapes will be within the middle of the graft. So we have our two cerclage sutures on the femoral and tibial side. And you can see the internal brace as I pull it slides easily. So even though we have the the linking sutures, it does not grab the internal brace so it stays totally independent of the graft, which is critical. So we're going to drill the FlipCutter. So there we are. Take the six over nine guide out. So the first step here is to pound the guide sleeve down. You can see the ten millimeter FlipCutter. Then we'll pass our FiberStick. Just use a simple loop grasper to retrieve that. For our passing suture. Then we'll dock this. So our FlipCutter comes out directly where we wanted it to in the ACL footprint. So we'll RetroCutter our tibial socket. To shave her in place. That debris out. So now we're going to pass through our TigerStick. Here's our loop Grasper. So this will be our shuttle suture on the tibial side. So now we're going to pass our graft. We have to retrieve our docking suture from the femoral socket. Having the passport cannula in place makes this very easy now. So here's our femoral docking suture. That's out the passport cannula with our tibial suture. What I'm showing here is a nice trick to allow for easy passage of your button on the femoral side, so you don't have to use X-ray intraoperatively. So we know our intraosseous distance we measured when we created our femoral socket was 40. So what we're doing is just marking our strands at 40, but it's from the distal end of the button. Because remember, what's going to happen is the button is going to go out the small femoral hole. And we expect it to flip on itself at 40mm from the end of the button, which would be the aperture, the hole on the femoral side. So when we see those blue marks pass into the femoral socket, we know the button will be outside on the femur and it will flip easily. And it's right on the bone. And it's a nice way to do it without having to use x ray. Intraoperatively. So first thing we do is we pull those four sutures out the femoral side, and then I'll put the scope back into the joint. We'll watch the button pass. And here's the button. You can see the FiberTape pass through the button as we did initially. And we're going to look for that little blue mark where we measure the interosseous distance where we expect the button to flip on its own. So it's a little bit under the tapes. There. There it is. So you can see our blue mark coming through the passport cannula with the graft. There's the blue marks. So Right right there. That point, the button just flipped right the aperture there at our 40. So we pull back, you can see we've got we've got our fixation now. Now a key point right here is I like to pull the slack out of the tapes. So now we're going to hoist the graft up into the femoral socket with the TightRope T shortening strands on the femoral side. It's important to keep some degree of tension on the tapes just so there's no slack of the independent InternalBrace. So we've marked the graft. Graft was 63 long. So we're going to pull it up 20 into the femoral socket with our intra-articular measurement of 23. So there's our graph going up into the femur. We'll go to the blue line right there. Perfect. And then we'll pass the tibial end of the graft with the no button loop into the tibia. And we took the slack out of the tapes. So the next step is going into the tibia. Another important point here is you never pass the loop alone? We always put a shuttle suture to protect the loop. So we're going to pass the two ends of the tape and the shuttle suture for the TightRope. No button loop into the tibia. So now we deliver the two tapes and then we'll deliver the TightRope. No button loop out the tibia and then the graph will pass. There's our graph going into our tibial socket. We'll pull that down. And you can see we're right pretty much on our numbers 23 Intra-articular distance. There's our graft in good position. And so now we can address the tibial side. First thing we'll do is we're going to take out our little passing loop for the no button TightRope. So that number two we just pull that off now. So now we're going to apply our button the ABS button to the no button loop. So attachable button system. This is a 14 millimeter diameter button. It's perfect for the independent internal brace because there are two accessory holes in the button to allow separate passage of the tapes through the button. So we're going to come in first and apply the apply the shortening strands on each end of our ABS button. So now what I'd like to do is I like to shorten the shortening strands here a bit on the tibia. So I'm just going to take some of the slack out of the system. I'm not tightening it all the way. I bring it down to about here. So now we're going to pass the independent InternalBrace tapes. So what I'm going to do is pass one tape for the independent InternalBrace through the one buttonhole. And then the other tape through the other hole. So now I have the tapes passed a huge point here is everything we're going to do with fixation of the independent InternalBrace. And the graft is at full extension or hyperextension if they have it. What I'm going to first do is just I'm going to bring the shortening strands down. I'm not tightening the tibial fixation. I just want to bring the button down to the tibia. And and that little nub fits in that hole. I just pushed it in like that. So I've not put any tension on the shortening strands at all. The reason is because it's going to be independent fixation. I'm going to first fix the tape ends for the internal brace and then we'll fix the tibia. Finally with the shortening strands. The important point right now is to make sure all the slack is taken out on the table side. For my fixation of the two tape ends, we use a 4.75mm biocomposite SwiveLock. And so we have a step drill to make a 4 or 5 hole. And generally I'm about a centimeter or so distal to the button. And you can see our button right there. So come in with the drill just about a centimeter or so here on the tibia. And I drill the step drill down like so. You always have to tap the tibia. This bone is hard. So even in this cadaver it's not bad. So we tap that and then we're going to get our fixation for the independent internal brace. Race, we're absolute full extension. I've already taken the slack out of the tapes. One thing that's helpful here is you don't want the tapes to be too tight. You can add a little hemostat here if you want to, to put a millimeter of slack before you fix the tapes. But actually, because they kind of come over the button, there's almost a millimeter of slack built in that way. So now again, we're in full hyperextension of the knee. I find my hole right there. Remember this is the independent internal brace. So we take this right to the cortex. Undo our sutures, and we can just check, make sure we're deep enough. Back this up clockwise. Looks like I'm perfect right at the cortex. Vortex. So at this point, I do not need this suture that was in the SwiveLock the tapes are fixed. I can cut the tapes. Internalbrace is done. Now we need to fix the graph because I haven't fully tightened the tibia. I'd like to use the tensioning handles because you can get additional strength. So. Plus it really is a lot easier on your fingers. And now what I like to do is cycle the knee. And I'm pretty vigorous at this step where I really want to take this knee through a range of motion 25, 30 times. Put on the graph, put a little draw. Lockman on the graft. Any creep I'm going to get out of the system. So I think this is really important because what I'm going to do, and this is the advantage of the all-inside technique with suspensory fixation on the femur and tibia, I can retention. So I can take out any slack in the system that might happen here just from ranging the knee. So I really put some force on it here. Lockman Pivot, do it. Intraoperatively. So now, once I've done that, we go back into our fully extended position. We're going to take out our passing suture for the femoral button because we know we're in good position on the femur. We're going to apply the tensioning handles now to the femur. And just as we did on the tibia, again, keeping the knee fully extended or hyper extended, we're going to retension. So if there was any creep in the system just from doing that vigorous range of motion, we can take it up at this point. Once we do that, I come back to the tibia and I do one last time on the tibia. So this is my sequence. First fix the two tape ends for the internal brace full extension with the swivel lock. Then I do my preliminary tibial fixation with the handles, cycle the knee vigorously, and then do the femur again in full extension or hyper extension and the tibia one more time. And then since the sutures are right here, I go ahead and tie these to my button because this does give me some backup fixation. Remember, I showed you my buttons right on the bone. And so I just go ahead and tie my no button sutures here. Down to the button here. Just give me a little additional fixation. I've never had to take a button out. These are low profile. So that's the completed all-inside technique with the independent internal brace. And we'll take a look at our graft. So here's our final construct. And you can see the quadruple semitendinosus. Notice you don't see the tapes for the internal brace the way I showed you the graph preparation. The tapes are inside. Got great tension on this graft and bundle attachment. Femur tibia. Isometric tapes in place. Very secure. Good position of the graft. Remember I only use the semitendinosus, so I preserve the gracilis. Another advantage of this technique all-inside. You just need the semi only to quadruple. For the purposes of this demonstration, I'm going to dig into the graft a bit to find the tapes, because I want to show you that there is going to be laxity of the of the tapes inflection. The normal ACL goes through a loosening pattern from 0 to 90 of three millimeters. So the tape was fixed in full extension where it would be the tightest. But it's going to be lax in flexion. So I'm going to bring my probe in. And I'm going to open up this graph a little bit see if we can find the tape. Here's one of the tapes. And you can see right here look at the laxity of the tape. We're at 90 degrees of flexion. You can see the tape. It's not too tight. The tape is an internal brace. We want the graph to see load. The tape is only going to kick in at a high load where there could be a stress to retear the graph. That's where we want the tape to protect the graph. We want the graph to remodel and revascularize and it will do that at the lower loads. So that gets really important point. Here you can see nine degrees of flexion. The tape has laxity. But again it's right within the graft. So it really looks nice at the end.

Thomas M. DeBerardino, MD (San Antonio, TX), demonstrates a GraftLink® technique for PCL reconstruction using the new TightRope® II implant and InternalBrace™ technique.
InternalBrace surgical technique is intended only to support the primary reconstruction and is not intended as a replacement for the standard of care using biologic augmentation in a primary reconstruction. InternalBrace surgical technique is intended only for soft-tissue-to-bone fixation and is not cleared for bone-to-bone fixation.

GraftLink® PCL Reconstruction Using TightRope® II Implant With InternalBrace™ Technique

Hi, I'm Thomas Diberardino from San Antonio. Today we're going to show the new All-inside PCL technique using the new TightRope two RT with preloaded internal brace. And then on the tibial side, we're going to use the TightRope two with the new ABS. So here we have a left knee. We've taken out and established the femoral footprint here through the lateral portal. We have a generally intact ACL. And now we're going to come into the medial portal. And we've pre dissected out the tibial footprint. The back of the capsule is there. You can see the mammillary body on the medial side here. And a little peek into the mammillary body on the lateral plateau through that small rent at the 5:00 position. But there's our posterior capsule and our completely denuded PCL tibial footprint down to bone in the posterior capsule in the foreground. All right, so our first order of business now is to establish our tibial retro socket. I like to use the round guide because I keep it intra-articular. You can use the over the top guide with an ACL intact. It's certainly easier to put the arthroscope in the lateral portal to get kind of a top down view. We bring our round guide back to the back of the knee, and we abut it up against the capsule. And I can see the capsule there, and I know the mammillary body is there, so I've predetermined through my more direct medial portal view where I want this to lie. I do not see necessarily the lateral extent, but I know I'm centered up because those are the visual landmarks that I cued into through the medial portal. So I go up against the posterior capsule that's as far down as I can be. And look, I'm also 12mm down from the plateau is marked on the guide. So I load that in with a sharp tines, and I set the angle of attack based on where my portal is at about 70 degrees, and we make a mark on the skin and then a then a vertical incision. And this is the same all inside cruciate. Guide system. So it's going to have that seven millimeter offset cannula that's going to punch into the tibia. Once we determine that we like our position we'll bring the sleeve in keeping our view up top. I'll have someone else hold the arthroscope. We'll use the FlipCutter three for a graft match size diameter of a socket that will make his ten millimeters. So we'll roll our our sizing device. We roll it to ten. I'm looking down at the guide. I'm holding it with one hand. I'll let go for visualization purposes. Now we go in with the FlipCutter three. It's going to be about 40 to 45mm at this tibial socket length. And we're looking for a breach of the cortex. Now we're 4/5 of the way in at least. So we've actually done the job. So we'll cut through. We'll see the tip. There's the bubbles. It's right in the hole I felt it center up. You can feel the the echo or the reverberation. So take the guide off. It now can actually act as a retractor, so I can actually rotate it to the side like that and spin the drill a little bit. There it is right there. Walk it out enough so that the laser mark is visual. There's the laser mark right there. Good. So we'll take that out. Oftentimes we'll take a shaver in there. Then we'll go up to 12 and then back to 3.5. Hold our sleeve and pull out our drill. So we own that cortex. We'll stick a shaver in there before we stick any suture up and just clean out some of the debris. And this can be done concurrently with drilling or after if you have limited assistance. Reasonably clear. Now we can stick it in a posterior medial portal which we previously established. It's good to get all this debris out because it's definitely a low point on the knee, and any bone remains are going to settle down in there and block your graft. So there's our socket there. You can look at it through the medial portal and we'll deliver that suture up. I'll take a KingFisher. Again the scope will go back in the lateral portal for direct access with our suture retrieving instrument. And there's our TigerStick. We're grabbing the looped end, and that will pass our graft into the tibia. So that'll get locked off with a clamp. And we'll immediately turn our direction to the femoral socket. So we use the standard All-inside femoral PCL guide to use a FlipCutter three to fashion a femoral retro socket with a seven millimeter cortical mantle. We've pre-marked our position anatomically, and we know on the literature it's better to put this single bundle graft as high in the notch as you can and juxtapose to the cartilage, because the graft is going to settle low and deep in the socket. So we want the socket just up against the cartilage and at the top of the notch. We start the guide at about 65, and we may adjust it based on, again, where our portal is, because that's the zero point. I'm going to have my assistant hold the scope and keep that in view. I want to see the apex and the wall and we know we're offset from the cartilage. This is a nine millimeter socket and a ten millimeter graft. So I can put that just about up against the cartilage, roll my hand down a little bit and then make a cut down incision. I'm going to lower that angle just a little bit right there. Put it about 55. It looks as good. So we'll bring that in there with an incision. Now we'll take an 11 blade make a little one centimeter stab incision with dissect down but get down to bone. Not too much tension just enough to lock it down. We like the position of our socket internally. And then we'll drill in. We'll put the grommet offset about 30 because we know it's never more than 30. It's probably going to be more like 25. So these retro sockets on the femur, if you put them in the anatomic position are rather short with a seven millimeter cortical mantle. We're about to breach the cortex, so we get ready to slow down on the drill. High speed, low push. We come in. It's pretty much committed now because it's got a good cortical mantle. So I could pull the sleeve off or watch it come in right into the center hole. There's the bubbles forming. There it is. We'll hold there because that's a perfect spot. I'm going to go ahead and take it off and watch it come in. Now with the mount I'll pound the sleeve in because we like that spot. Definitely like the start position. Now we'll finish off the drill. You can see where it's about to come through. I'll get the shaver ready to get some of the debris. That's a perfect spot. So pull it back a minute. Let me just clean up some of the bone. Then we'll get you back in and we'll show the laser mark. You have to extrude the pin in the drill. The FlipCutter through to the laser mark right there to be able to deploy the FlipCutter device. So we'll protect our ACL here. We'll roll it down to a ten. And then I'll have the shaver here just in time to do bone extraction. I'll put it on now as we start to pull back. We already we hang on with one hand with our sleeve that's inset seven millimeters, and we pull back our FlipCutter three until we hear a hard stop on metal, which is the inner sleeve. So it's going to be a nice hard stop. That's good. I'm getting all the debris out, which is nice. So we'll be able to look up here and see just kind of go in and out, plunge and control it and deliver some of that bony debris to me. Go ahead and pull that out. Now. Should free flow, we can look up that socket and there is a nice socket and we can see the inner sleeve of our guide. We'll stick our stick down our loop. Fiberstick. So here we are putting our passport in. So we've got our grommet. We'll redeploy our tibial suture. So we're retrieving all our sutures at the passport, because we want to make sure that there's not a soft tissue bridge. I'll go with the 12:00 spot above that one to retrieve the femoral loop. And now I've got good control of these sutures. So this is only an eight millimeter passport. It's good for just prep and fluid control. We're not going to be able to pass a ten millimeter graft through that. And that's not the intention as we're ready to get the graft. I had enlarged that portal before I put the passport in. So this gives me a good fluid control to get a good picture and to kind of keep the knee insufflated with fluid and not let it bleed or fill with air. Here we have a pre-configured quadruple stranded soft tissue graft in the compression tube on the femoral end. We have the TightRope two PT with a preloaded internal brace, and on this side we have the TightRope two ABS and the compression sleeve has been on it while we did the knee prep, so it condenses down the graft. It's got little portals. If you want to baste your graft with some sort of biologic of choice, you can put ACP in here or BMA or the biologic of the surgeon's choice very nicely. And it's contained as a little bioreactor. It's been under tension. It's kept moist in the tube. And most importantly, it's compressed so that it's truly a ten going in ten sockets on the femur that we've prepared in the tibial socket. Likewise. So we're ready to take our graft off. We take the tension off with the squeeze bar so it doesn't fly across the room. We retract the button holder on the femoral side. I is a surgeon now. Will grab the graft. Somebody else will shimmy off the compression sleeve. Will grab it to control this. As we walk toward the table, we'll take the abs off the tibial hook and bring our graft over to the table. So a couple of key points we want to talk about with the new TightRope two. First of all, it's preloaded with the with the internal brace, so we don't have to go through the difficult task of feeding a FiberTape up and down through the little tiny holes on the button. Secondly, the TightRope two utilizes the SutureTape, which we know is more tissue friendly. It's flatter, it's broader, it's stronger, and it slides easier through the looped end of the graft. And the last thing which every surgeon will appreciate is the SutureTape is easier to tighten with less friction at the glove skin interface of the surgeon. So there's less tendency for it to make a burn or a cut into your skin around the index finger and thumb when you're tightening the sutures. So we'll reposition our arthroscope in the lateral portal. Now we're viewing everything through the lateral portal, and we have our sutures lined up with the femoral suture secured and protected above. Here. We've taken out our passport. Now, it did its job. It negated a SutureBridge and kept fluid control. We've enlarged this portal beforehand, but now we've taken it out. So we're ready to pass our graph. So we've got a little bit of extra fluid through an enlarged portal. We're going to pass the tibial end and all the sutures that go with it into this TigerLoop passing suture through the tibia. So we've got our internal brace and the grasping suture that's grabbing the saddle of the abs tightening mechanism and implant. We're going to pull those down through the tibia. Deliver them out. So we've got the internal brace and the grasping suture that's pulling the abs destined for the tibial side through. There it is. There we can pull the tightening sutures out. Now our delivery stitch at the saddle comes off. I'll put my finger in the loop. Keep a little resting tension on the IB pulling the GraftNet. We can watch the graft come in from the front. There it is, there going down behind the ACL. We keep our femoral sutures taut up here so they're out of harm's way. We deliver the graft down in the back. You saw that, mark. So now we can look in as best we can from the lateral port. And we can see it's gone down and into the socket. The blue mark is gone. So now we can immediately hold fast here and go to pass our tibial end. So we'll keep resting tension here with an assistant's finger through the loop. And then grab the tapes with your thumb. And now we'll redirect the femoral side using the femoral passing suture that we replaced a while ago. We'll do the same thing for the femur. We'll pull the passing sutures up, shorten the tails. Pull them through. And Unloop them and start to milk them in. I'm keeping back tension through the loop with my finger, and that can turn toward a probe so I can keep a little tension so that button doesn't come flying out of the skin. Get our button to deploy. We'll look up the socket and watch it deploy, because we know once the trailing edge of the button hits that cancellous bone, we only have seven millimeters to go. So at this point, I can take this out. The button there, I can rock my hand. And that way I don't walk away. The button's out. So now I can pull back on the tibia. And I know I've got some tension on that now. Sometimes I'll stick a probe down here. The IB controls the button, so if we keep tension on the blue sutures here, that will pull the button back and seat it there. That's seated. Nice. That's good. So now we'll use the tightening sutures to pull the graft into the femoral end. Nice. So that's in now. So this having this preloaded internal brace can't be understated. What it's doing here, it's keeping the button up against the cortex. And the tightening sutures then are literally just pulling the graft in. So that's good there. So we aren't done there. So what we want to do now is either look from a posterior medial portal hanging onto this internal brace suture. I'm going to try and look above the graft down up over the uprights through House triangle and look down back at our at our graft. There's our graft right here. I'm going on both sides of it. I can see down. So enough is in the tibial socket. I don't see the blue mark. It's gone. So I know I've sunk enough in the tibia and I've got some space in the femur. But remember it's a shallow cul de sac. So we'll do our final tightening On the tibia and then do an anterior drawer inflection and do final tightening on the femur. So now I'm going to take the scope out for a second. So now our focus is and attention is drawn toward the tibial side. We'll cycle the knee get it into the tibia just a little more so that we don't bottom out on our femur. But we know we're pretty balanced. So we've loaded our internal brace sutures through the eyelets on our ABS button. We've fed in our abs loops into the slots on the top end and the other opposite end. That's a rail system. So we're going to hold these under tension as we deliver the button up. So the IB InternalBrace sutures won't change length. But they're the rail system in line. And then we slowly tighten our button down to bone. We feed it in through our small incision. And this button is nice because it will inset right into the 3.5 external drill hole on the tibia. And with a knee inflection Flexion. I don't need to do a draw yet. It can just be in resting flexion. Now before we do our final tightening on the tibia just below the button, we're going to pilot a drill hole for our swivel lock. There's the edge of the button. So we'll drop down about six millimeters. And I use the bottom of the incision as a soft tissue guide. As long as there's no tension. That's our permanent mark. So we drill into the tibia depth stop guide. You can see the hole. It's at the bottom of the incision. So that's just a nice mark. So we're using the new 52 tap. It's perfect for the harder bone especially on the tibia for like for this type of situation when you're doing a swivel lock for a root repair to it's just a nicer 5.2 tap. So use that henceforth on your tibial side. You'll be happier. Get that into the laser mark. And if there's a soft tissue envelope, you have to adjust how deep you go here by the offset of the soft tissue beyond the laser lasermark to make sure you fully tap. So we've preloaded our anchor. We've got the internal brace tails only because this is just the hole for the internal brace. So I'm going to take out the tap find that pilot hole. Put the tip in. Based on recent research looking at laxity or over tightening, you always have about 40 pounds of force. So I have just resting tension on this. I'm not being Hercules here. I'm just getting tension through my ulnar grip. And I'm tapping in the plug so it keeps resting tension. When you hear the device hit the bone, start delivering it in through your pre tapped hole. You'll hear some kerning as it engages the threads. And this is a tight fit. But it's a nice easy fit to you. Can feel good tactile feedback. Spin your sleeve back. You can check with the probe. In this case I can see directly threads are flush. Device comes out with a tap of a of a mallet. We've pulled the retaining suture, and now we just have the the internal brace FiberTape, and they get cut flush. So we've cut that internal brace off. Now we can do final tightening on our tibia with the tightening sutures left right, left. And then we can tie them off and cut them. So then we do our final tightening on the femoral side. And then we can either just cut which I usually do or you can tie several throws. So we'll just cut them flush below the skin. And then our draw is nice. We've reestablished the anterior tibia. There's no more posterior draw that there was before this isolated PCL case reconstitution with an all-inside PCL soft tissue graft using the new graft construct and the TightRope two with a preloaded internal brace.

This animation demonstrates the ACL GraftLink® technique using FiberTape® suture for the InternalBrace™ technique.&nbsp;
The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.&nbsp;

GraftLink® Technique Using FiberTape® Suture for the InternalBrace™ Technique

Graftlink ACL reconstruction using a TightRope two implant and the internal brace technique. The GraftLink construct includes a TightRope two implant that is preloaded with FiberTape suture for the internal brace technique, and features new flat tape loops and tensioning strands for improved strength and handling, and a broader suture graft interface. The TightRope two implant uses an improved button design, incorporating a proprietary knotless fifth locking point that increases strength and resists cyclic displacement. Place the ACL femoral guide over the ACL femoral footprint. Arthroscopically. Adjust the angle of the guide to the desired position and tunnel trajectory, and then lock into place. Push the ratcheting drill sleeve down to bone. Advance a FlipCutter three drill pin through the ACL femoral footprint. Tap the tapered portion of the stepped drill sleeve into the femur seven millimeter or until resistance is felt when reaching the femoral cortex. Using the wheel, deploy the FlipCutter three. Drill to the appropriate size and retrograde. Drill back to the sleeve to create a socket. Remove the FlipCutter three. Drill and pass a blue and white FiberSnare suture through the drill sleeve. Retrieve it from the lateral portal and dock it for later graft passage. Remove the stepped drill sleeve. Place the ACL tibial guide over the ACL tibial footprint arthroscopically. Adjust the angle of the guide to the desired tunnel position and tunnel trajectory, and then lock into place. Push the ratcheting drill sleeve down to bone. Advance the FlipCutter three. Drill through the ACL tibial footprint. Tap the tapered portion of the stepped drill sleeve into the tibia seven millimeters or until resistance is felt when reaching the tibial cortex. Using the wheel, deploy the FlipCutter three. Drill to the appropriate size and retrograde. Drill back to the sleeve to create a socket. Remove the FlipCutter three. Drill and pass a black and white FiberSnare suture through the drill sleeve. Retrieve both of the FiberSnare sutures from the medial portal, and remove the stepped drill sleeve with the blue and white FiberSnare suture. Pass the femoral side of the GraftLink. Construct into the femoral socket until the button flips on the femoral cortex. Use the tensioning sutures of the TightRope two implant to advance the GraftLink. Construct into the femoral socket with the black and white FiberSnare suture. Pass the FiberTape suture for the internal brace technique and the abs. Tightrope two. Implant into the tibia with the knee in extension, use an 11mm, three hole concave button for tibial fixation of the GraftLink construct with the FiberTape sutures for the internal brace technique loaded through the larger oblong hole before tensioning the GraftLink construct. Anchor the FiberTape sutures for the internal brace technique using an ACL backup fixation kit. Using the spade tip drill followed by the 5.2mm tap, place the FiberTape suture for the internal brace technique into the eyelet and screw the 4.75mm SwiveLock anchor into the drilled hole. Take the knee through range of motion and then perform final tensioning on the GraftLink construct.

A list of scientific articles pertaining to a product or procedure.

Eine Liste wissenschaftlicher Artikel zu einem Produkt oder Verfahren.

Wissenschaftsupdate

Lista de artigos científicos referentes a um produto ou procedimento.

Atualizações científicas

Lista de artículos científicos relacionados con un producto o procedimiento.

Actualizaciones científicas

Scientific Updates

GraftLink® Technique Scientific Update

Autograft ACL-Rekonstruktion mit Hamstring

Für primäre und revidierte Bandnaht- und Rekonstruktionseingriffe steht eine Vielzahl von Sehnen-Allograften zur Verfügung, darunter auch eine breite Palette an vorgenähten Sehnen.&nbsp; Allograft-Sehnen bieten gegenüber Autograft-Sehnen bei Rekonstruktionen viele Vorteile, dazu zählen eine geringere Entnahmemorbidität,1,2 weniger Inzisionen, eine kürzere OP-Zeit,1,2 größere und kalkulierbare Transplantate,2 und weniger postoperative Schmerzen und Steifigkeit.2
Wählen Sie zwischen sterilen oder aseptisch aufbereiteten Sehnen. Sterile Sehnen von unseren Partner-Gewebebanken werden sterilisiert, ohne dass sie biomechanisch oder biochemisch verändert werden.
Vorgenähte Konstrukte sind gebrauchsfertig und mit nur minimaler erforderlicher Vorbereitungszeit einsetzbar, sodass dem/der Operateur:in ein hochwertiges, konsistentes, steriles und stabiles Sehnen-Allograft zur Verfügung steht.
1. Edgar CM Zimmer S, Kakar S, Jones H, Schepsis AA. Prospective comparison of auto and allograft hamstring tendon constructs for ACL reconstruction. Clin Orthop Relat Res. 2008;466(9):2238-2246. doi:10.1007/s11999-008-0305-5
2. Greenberg DD, Robertson M, Vallurupalli S, White RA, Allen WC. Allograft compared with autograft infection rates in primary anterior cruciate ligament reconstruction. J Bone Joint Surg Am. 2010;92(14):2402-2408. doi:10.2106/JBJS.I.00456
Haftungsausschluss:&nbsp;Allograft-Produktangebote hängen von der individuellen Länderzulassung und der Produktverfügbarkeit ab.

Orthobiologics

Arthrex offers a variety of tendon allografts, including a wide portfolio of presutured tendons, for primary and revision ligament reconstruction procedures. This animation highlights the comprehensive presutured allograft tendon portfolio and potential applications.&nbsp;

Presutured Construct Tendons

Allograft Tendons: A Comprehensive Portfolio

Allograft GraftLink® Construct

Michael G. Baraga, MD (Miami, FL), performs an ACL reconstruction using a QuadLink™ presutured allograft, a TightRope® II BTB implant preloaded with FiberTape® suture to perform the InternalBrace™ technique, and a TightRope II open ABS implant.
The InternalBrace surgical technique is intended only to support the primary repair/reconstruction and is not intended as a replacement. The InternalBrace surgical technique is intended only for soft tissue-to-bone fixation and is not cleared for bone-to-bone fixation.

ACL Reconstruction Using QuadLink™ Presutured Allograft and TightRope® II Implants

So the QuadLink graph is a pre sutured quadriceps tendon construct. It comes prepared with FiberLoop with FiberTag for secure fixation and addition of our TightRope constructs, very similar to the GraftLink with the new TightRope two implants. The first thing you'll notice is an improved packaging, which allows an easier deployment and building of the construct. The first change you'll notice is the addition of SutureTape, which provides less stress on the graft, wider area of contact, as well as an improved strength of the construct. It also has an added locking mechanism which helps reduce cyclic displacement. Another key feature that you'll notice is also the addition of the FiberTape included already in the construct, which really helps speed up the building and putting together of the entire graft construct as the tape is already included in the button. And finally, a nitinol wire to help assist with building the construct and shuttling the sutures internally. So our QuadLink allografts come in sizes ranging from nine millimeters in diameter to 11mm in diameter, and lengths ranging from 68 to 73mm. Perfect for the all-inside technique. What you'll notice once you take it out of the packaging is you have one side with one set of sutures, and the other side with two sets of sutures. The second, thinner set of sutures serves as a tibial backup fixation. If you're interested in using this into a SwiveLock anchor, you can keep these in the construct. However, if not, you can always remove these prior to graft preparation. Okay, so for this construct we are going to use the BTB TightRope two with internal brace for the femoral side and the TightRope two ABS for the tibial side. All right. So we'll start our graft preparation with the tibial side with the TightRope two abs. We'll start by cutting off the needle since it will not be necessary for this graft construct. Once the needle is off and the loop of tape is unraveled, we can take this to the graft. We'll take the loop. Once we pass the loop through the loop, we'll fold this down, pull through, get it engaged, and then pull firmly to pass it through the other side. Once the loop of tape is through the graft, you'll want to take the free limb of the SutureTape and pass that through that loop and then into the nitinol wire. Once it's in the nitinol wire, you want to secure the card and pull firmly proximally to build the construct. Now you'll want to remove the sutures from the card. Once the construct is built, we can then pull on the free limbs of the tape to even out the construct and set it at the appropriate length. So for our femoral side, we'll use our BTB TightRope two with internal brace. We'll start by cutting off the suture From the needle. So we don't need the needle for this construct. And we'll then un cinch also the loop suture to shuttle through the graft. All right. So through the loop of the shuttling suture we'll pass the loop of the suture tape from the TightRope and pass this through to the other side. We'll take the free end of the SutureTape, which is the number two, and pass it through the loop that was passed through the graft. We'll then bring the free end back in through to the card to the nitinol wire loop, where we will set this. Pulling proximally and holding the card firmly at the top can easily pull this through and finish building the construct. All sutures are then removed from the card, including the internal brace which is in the back. And now we can separate the sutures and pull on the free ends in order to set the appropriate length of the construct. Okay, so here we have our final construct of our QuadLink allograft. And what you'll notice real quickly if we look at the graph, this graph is under 80 newtons of tension. Right now. There is no gapping in the TightRope in either end from the construct pulling away. So this is number one. It's a secure construct. So second, what we've done also is we've taken the tape sutures from the internal brace and passed these through the whipstitch sutures on the graph. Now these are loosely passed through. So these can really slide easily. They won't hold the graph back in terms of graph passes, but it does keep the tapes tight to the graft to help with deployment. And on the tibial side, we've added a safety stitch to pull when we're pulling the graph through into the tibial socket. And we've also marked the free ends of the TightRope mechanism to easily identify them as the free limbs once they're pulled through. Now that we have the final construct, we can go over to our Arnie for demonstration of the surgical reconstruction technique. So we are in this left knee and we've already cleaned out the the ACL. And we can see visualizing from a lateral portal. We can visualize the wall. We can see the extent of the native femoral footprint. We can also see on the tibial side the extent of our tibial footprint with a great view across after resecting the fat pad. Now for femoral socket preparation. I do like to visualize more from the medial side, and I do use a three portal technique which does allow a low anteromedial portal, which I've already established as close to the femoral condyle and as close to the meniscus as possible, but safely. And now we can see where we are, we can see the footprint entirely, and we can bring in the offset guide. Now I trained using an offset guide. So this is what I've always used. But I basically use it as sort of a guide to float the pin to the spot that's going to be in the middle of it. Now we can see the knee in this position, but once we hyper flex to really get that angle, we angle, we flex the tibia. Here you can see how that footprint, if you keep going, kind of rotates a little bit more anterior. So if you just place the guide posterior and forget about it, you might be a little too posterior. Whereas in this scenario it might be a little more favorable to float the pin more so into the center of our footprint where you can see this a little bit easier right here. So this is where we would be if we were off the back wall. You can see the center of the footprint is slightly anterior. So we'll place the pin right in the center of that and we'll get ready to fire that across. With the pin held in the center of the footprint. We can fire it in from here. Or we can get the guide out of the way and really inspect where our positioning is in the center of the footprint. And we can also visualize also from the lateral portal. Where we can see where we are in terms of the posterior aspect and the anterior aspect. So we'll get an LP reamer size to our graft. For an all inside technique, I typically go between 20 and 25mm depending on the size of the graft right there. And again, you can take this moment to really see the extent of your socket and how it fits inside the footprint compared to the reamer. All right. So let's take that to a depth of about 25. Perfect. All right let's get the reamer out. All right. All right. Cool. We'll pull our shuttling suture through keeping the loop on our end. Yep. And then we can just cinch this on the back over here. Perfect. All right, now we'll go to the tibia. Mark our spot that I've already marked with the RF and set our target line. Mark the skin. Make our incision. We'll take the guide off and visualize. At this point, we can see it from the medial side coming in more medial than lateral. We can see it right behind our anterior most fibers right in the center of where the majority of the ligament lies. We'll mallet this into place. All right. We'll take this a little bit higher. Make sure we have clearance. And we'll go ahead and take this back to a depth of 25mm. We've pulled our femoral suture shuttling suture into the joint. We're ready for our passport cannula. And now we can retrieve the suture out of our passport and get ready to pass the femoral side of our graft. We're ready to pass our femoral side, so I'll hand over the sutures. Pass them through. We'll pull on the femoral side. Yep. Pull those through. Perfect. All the way through. All right. And now we'll get ready to pull the graft into the socket. I personally like to switch over to then to my more central portal. And that gives me a view straight up the socket so I can see when the button is deploying. So we'll go ahead and pull these as you usually would with any other TightRope mechanism. All right. And as we start getting closer all right you can see the button coming up to the aperture. So at this point we'll just pull on the blue sutures. Got that to pop through. And that's it. And then you can see it directly flip. And then we can pull back inside the abs and feel that flip back on the cortex and you can hear almost hear it. Back on the cortex. No need for fluoro. No need for any other verification there. So once that is set, you can pull on your tapes, keep that button on that cortex. And then we can start synching the TightRope mechanism on the femur. You can keep tension individually on those tapes. This will slide right over them. Yep. There we go. Perfect. We'll graft going into the socket. Good. You can always with good press fit. Sometimes you have to assist a little bit at the edge with the probe. All right. There we go. Perfect. All right. Excellent. We'll stop right there and we'll finish bottoming that out later. Now we'll hold all the sutures here. Let's pull these proximally and we hold tension on these up. I'll slide on the bottom of our passport into the bottom over here, where we'll push our TigerStick and we'll grab that suture. We pull that back a little bit. Perfect. Got it. Excellent. All right, so our sutures are here. We'll take now the tape, sutures and our blue cinch suture. So for this, we've identified what our tensioning sutures are. We'll keep those out of this. We'll take our safety stitch and our tapes pass them through. Once everyone is in, we'll pull on the tiger. Shuttle that through. Everyone comes through. We can now pull everything down. We've now identified already which one our tensioning sutures are. Which are the purple ones that we marked. So we can easily bring these down from inside the joint. We can pull our passport back, which can sometimes get a little bit in the way we don't need it anymore at this at this moment. And we'll go ahead, dunk our graft, pull tension on our tapes, and our graft is seated into the tibia. And we can now see our construct from the tibia to the femur. You can visualize it also from the anteromedial aspect. Coming down into the footprint you can visualize range of motion as we come into extension. And we'll proceed then to fix this on the tibia. So we'll set up for tibial fixation. Now the first thing we do is we remove our safety stitch from the tibia. Simply pull that little cinch off okay. We'll take our 11 millimeter. Button. We'll load. Our tightropes On either side, and then we will load our internal brace on the sides of these as well. We'll hold our tapes out. We'll provisionally bring this down to the anterior aspect of the tibia. Now this is not setting any tension yet. We're just basically sliding this down to the cortex. We'll place the knee in the appropriate position. Near full extension is what I prefer. And then now we can fix our internal brace into a swivel lock anchor. And then we'll recycle and tension our graft. We'll take our sutures from our internal brace and load them into a 4.75mm swivel lock anchor. Proceed to drill. Tap. And we'll hold the knee at full extension. Release our anchor mallet. Excellent. We'll go ahead. See that? We're down a few more turns. Perfect. Let's take our inner sutures out. Excellent. All right. Now, the knee will already be stable from the internal brace, but now we can cycle the knee, take it through full range of motion 25 times. Really? Test your lochmann. Test your anterior drawer pivot if you want. Really stress that so that we can now then come back and Retention. Okay, so we'll hold the knee posterior drawer. Okay. We'll begin with the tibia. And you can really feel the difference of the tape certainly on the fingers as you're re tensioning this. You can also appreciate how it will have the same effect on the graft. The broader suture larger surface area. So retention on both sides. Again you can reexamine feel. That'll be it. Remove the flipping suture. Cut these down and we're good to go. So yeah. So there's our construct with the QuadLink allograft using the TightRope two devices, both our BTB TightRope two with internal brace and TightRope two ABS on the tibia.

Allograft Tendons – Sterilization

Allograft AC-Gelenkrekonstruktion

Die BioACL-Technik macht sich die Leistungsfähigkeit von Biologika der nächsten Generation zunutze, um den ultimativen anatomischen, minimal-invasiven und reproduzierbaren Ansatz zu bieten, der die Ergebnisse für die Patienten auf ein neues Niveau hebt.
Durch die Vorfüllung von ACL-Knochenkanälen mit einem leistungsstarken Gemisch aus konzentriertem plättchenreichem Plasma (cPRP) aus Knochenmarkaspirat (BMA) oder Vollblut, das mit dem Angel-System aufbereitet wurde, dem mit dem GraftNet-Produkt entnommenen patienteneigenen Knochen und AlloSync Pure demineralisierter Knochenmatrix (DBM) bietet die BioACL-Technik alle notwendigen Heilungskomponenten für eine ACL-Rekonstruktion.
In Verbindung mit der QuadLink- mit der InternalBrace-Technik hat sich gezeigt, dass die BioACL-Technik im Vergleich zu nicht augmentierten ACL-Eingriffen zu einer früheren gesamten Bewegungsspanne, einer verbesserten Symmetrie der Gliedmaßen, einer geringeren Verbreiterung des Knochenkanals und verbesserten Ergebnissen nach Angaben der Patienten führt.1
Literatur
1. Lavender CD, Schaver AL, Taylor S, et al. Anterior cruciate ligament reconstruction augmentation with bone marrow aspirate concentrate, demineralized bone matrix, and suture tape shows no difference in outcomes—but faster functional recovery—versus non-augmented anterior cruciate ligament reconstruction. Arthroscopy. Online veröffentlicht am 22. Juli 2024. <a href="https://doi.org/10.1016/j.arthro.2024.06.042">https://doi.org/10.1016/j.arthro.2024.06.042</a>
Die InternalBrace-Operationstechnik ist ausschließlich zur Augmentation einer primären Reparatur&nbsp;/&nbsp;Rekonstruktion vorgesehen, bei der die Kontaktfläche des Weichteilgewebes während der Heilungsperiode vergrößert wird. Sie ist nicht als Ersatz für das native Band gedacht. Die InternalBrace-Technik ist für Eingriffe zur Fixierung von Weichteilgewebe am Knochen vorgesehen. Sie ist nicht für die Knochen-zu-Knochen-Fixierung zugelassen.

BioACL™ Surgical Technique

The BioACL™ technique augments ACL reconstruction with an unmatched combination of the patient’s own biology, the highest-quality biologics, and the proven technology of the QuadLink™ technique with the InternalBrace™ procedure to maximize healing potential.&nbsp;

The InternalBrace surgical technique is intended only to augment the primary repair/reconstruction by expanding the area of tissue approximation during the healing period and is not intended as a replacement for the native ligament. The InternalBrace technique is for use during soft tissue-to-bone fixation procedures and is not cleared for bone-to-bone fixation.

BioACL™ Technique Animation

Chad D. Lavender, MD (Scott Depot, WV), demonstrates an all-inside QuadLink™ ACL reconstruction with an InternalBrace™ augmentation after back filling the femoral and tibial tunnels with AlloSync™ Pure and autograft bone collected with the GraftNet™ device.

Augmentation of a Quad Tendon All-Inside ACL Reconstruction With Bone Marrow Concentrate Mixed With AlloSync™ Pure Demineralized Bone Matrix and Autograft Bone Collected With the GraftNet™ Device

Hello, this is Doctor Chad Lavender with Marshall University orthopedic sports medicine. And I'm going to present a case of augmentation of a quad tendon all-inside ACL reconstruction with bone marrow concentrate mixed with AlloSyncPure and autograft bone collected with the Arthrex GraftNet. This case is an 18 year old football player. He had a non-contact right knee injury, noticed a pop and an effusion, pain with weight bearing and he had a contralateral BTB ACL reconstruction I had performed one year prior to this. His exam showed 0 to 130 degrees. Range of motion. Positive. Lachman. Positive. Pivot shift. Moderate. Hemarthrosis. Here you can see his MRI showing the ACL rupture. So in this patient we elected to do an all-inside ACL reconstruction with quad tendon autograft augmented with bone marrow concentrate mixed with AlloSyncPure and autograft bone collected with the GraftNet device. Here you can see our technique video detailing this surgical technique. First, before the tourniquet is inflated, we aspirate 60 ccs of bone marrow aspiration from the From the proximal lateral tibia. Here's the quad tendon graft prepared on the back table. First, we will drill the femur in retrograde fashion with the FlipCutter. As you can see here, the GraftNet has been attached to the shaver which has been placed into the lateral portal. And as you can see, we are harvesting the reaming from the femoral tunnel using the GraftNet device. Here's the autograft bone within the GraftNet. Next, we will turn our attention to the tibial tunnel. A GraftNet attached to a shaver with suction has been placed through the medial portal. Here you can see the tibial tunnel reaming being taken up through the shaver and into the GraftNet there is the GraftNet with the bone graft within the GraftNet on the back table. In this case, we obtained four CCS of autograft bone using the GraftNet that was then mixed with five CCS of AlloSyncPure, which was mixed with five CCS of bone marrow concentrate. Next, the TightRope is then flipped on the femur. And here you can see delivery of the composite graft into the femur from the medial portal. We recommend fully filling the tunnel with the composite graft. Next, we will come from the lateral portal and deliver the composite graft into the tibia. We like to see slight fluid leak from the cannula, to allow us to know that we have properly impacted our composite graft into the tunnels. There is a view of the tibial tunnel completely grafted with our composite graft. Next, the femoral side of the ACL graft is delivered into the femur and the tibia is placed down into the tibial tunnel. We sequentially tighten the femur and then the tibia. And here you can see the final construct with an internal brace applied. Here are the patient's post-operative x rays. As you can see he's one year out on the opposite knee from a ACL reconstruction. He has obvious tibia and femoral tunnel widening. He's six weeks out on the fertilized ACL reconstruction. And you can see a significant improvement in his bone.

Die BioACL™-Technik

Angel-cPRP-System, mit Aspirationsset mit Antrieb (mit ACD-A)
